ORIGINAL INSTRUCTIONS
S/N: 3210 AND ABOVE
PLEASE CONTACT GAGE BILT FOR
ALL OTHER SERIAL NUMBERS.
GB752
INSTALLATION TOOL
GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE
E-MAIL US FOR A DISTRIBUTOR NEAR YOU.
GAGE BILT
44766 Centre Court, Clinton Twp., MI. 48038 USA
Ph: +1 (586) 226-1500 Fax: +1 (586) 226-1505
MADE in USA
solutions@gagebilt.com / www.gagebilt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GB752 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gage Bilt GB752

Summary of Contents for Gage Bilt GB752

  • Page 1 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS. GB752 INSTALLATION TOOL GAGE BILT TOOLS ARE AVAILABLE WORLDWIDE E-MAIL US FOR A DISTRIBUTOR NEAR YOU. GAGE BILT 44766 Centre Court, Clinton Twp., MI. 48038 USA Ph: +1 (586) 226-1500 Fax: +1 (586) 226-1505 MADE in USA solutions@gagebilt.com / www.gagebilt.com...

  • Page 2: Table Of Contents

    Overhaul ....................................13-15 Parts Lists ....................................16 DEXRON® III Oil Safety Data (SDS) ............................17 Accessories and Nose Assembly Selection Chart & Accessories ................. 18-20 GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 3: Eu Conformity And Warranty

    GAGE BILT DECLARATION OF CONFORMITY MANUFACTURER: Gage Bilt Inc. 44766 Centre Ct. Clinton Twp. Michigan U.S.A. +1(586-226-1500) WE DECLARE THAT THE EQUIPMENT SPECIFIED HEREIN CONFORMS TO THE FOLLOWING DIRECTIVES AND STANDARDS Machinery Directive 2006/42/EC EN ISO 12100:2010 EN ISO 13846-2:2012 EU REPRESENTATIVE Edgar Hausmann GmbH Förster-Busch-Str.

  • Page 4: Description And Technical Specifications

    (6.2 bar) air pressure at the air inlet. The GB752 installation tool is designed to operate on 90 to 100 psi (6.2-6.9 bar) of air pressure with 90 psi (6.2 bar) providing the maximum efficiency. At 90 psi (6.2 bar) air pressure, the GB752 does not exceed 81.5 dB(A) and consumes .16 SCF/cycle (4.53 L/cycle).

  • Page 5: Description Of Functions

    DESCRIPTION OF FUNCTIONS Hanger Head Cylinder Assembly Pintail Deflector Actuator Actuator Lever Assembly Handle Assembly Air Inlet GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 6: Warnings

    4. Support the weight of the tool in a stand, tensioner or balancer, because a lighter grip can then be used to support the tool. GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 7: Principle Of Operation

    Air Piston moves down Air exhaust Air exhaust Pressurized Oil Pressurized Air Unpressurized Oil Unpressurized Air Images may not reflect actual tool GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 8: How To Set-Up The Gb752

    NOSE ASSEMBLY HEAD CYLINDER FASTENER WORK RED SHIPPING PLUG USER QUICK DISCONNECT FITTING AIR INLET ACTUATOR AIR HOSE Image may not reflect actual tool. GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 9: How To Use The Gb752

    Press actuator to start cycle. Release actuator as soon as fastener breaks. Repeat steps 1-4. Images may not reflect actual tool or fastener GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 10: Maintenance

    WARNING: Tool must be maintained in a safe working condition at all times and examined on a daily basis for damage or wear. Any repair must be done by qualified personnel trained on Gage Bilt procedures. WARNING: Excessive contact with hydraulic oil and lubricants must be avoided.

  • Page 11: Filling And Bleeding

    Subtract dimension (A) from dimension (B). If stroke doesn’t check .500" (12.7 mm) min. follow bleeding procedure until stroke met. For your consideration, Gage Bilt offers a depth gage (Pt.# A-1935) to help simplify and more accurately check your tool stroke.

  • Page 12: Troubleshooting

    (See Nose Assembly Selection Chart pg. 18 and to select a Stroke Limiter). Tighten End Cap onto tool. (See pg. 10 for torque setting). Images may not reflect actual tool GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 13: Overhaul

    Perform overhaul in a clean, well lit area using care not to scratch or nick any smooth surface that comes in contact with an o'ring. Use of Lubriplate® (Gage Bilt part no. 402723) or other lubricant is recommended during reassembly to prevent tearing or distorting of o'rings.
  • Page 14 Insert and turn 5/8” open end wrench / adjustable wrench and snug tight approximately 1/4-1/2 turn. Reattach actuator lever assembly (704343) and pin-slotted (400608) to handle assembly (704132). GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 15 Valve spring installation tool assembly (704262) will facilitate the proper installation of the spring (704141). Valve sleeve (703139) can be pulled out using valve sleeve removal tool assembly (704163). GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 16: Parts Lists

    PARTS LIST GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 17: Dexron® Iii Oil Safety Data (Sds)

    Use material for its intended purpose or recycle if possible. Oil collection services are available for used oil recycling or disposal. Place contaminated materials in containers and dispose of in a manner consistent with applicable regulations. GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.

  • Page 18: Accessories And Nose Assembly Selection Chart & Accessories

    GB752 ACCESSORIES Approved for use on Gage Bilt CE installation tools and/or other manufacturer’s CE approved tools of similar design. (Sold Separately) Stroke Limiter NOSE ASSEMBLY SELECTION CHART #752142 Required with all right angle nose assemblies STRAIGHT RIGHT ANGLE OFFSET when used on GB752 tool.
  • Page 19 This page intentionally left blank GB752 S/N: 3210 AND ABOVE REV. 5/22 PLEASE CONTACT GAGE BILT FOR ALL OTHER SERIAL NUMBERS.
  • Page 20 Gage Bilt offers a wide selection of standard and custom kits tailored to your needs. Contact us for more information. Approved Approved Accessories Cont. Approved for use on Gage Bilt CE installation tools and/or other manufacturer’s CE approved tools of similar design. (Sold Separately) Catcher Bag-Stem Air Bleeder Assembly Split Riveter Tool Backpacks...
