Step 3：
Screw Coupler Bar(28L&R) on Front Post (42) with Screw (29), Washer (30), Washer (31) and cover
with Cap (24); Screw Pedal Tube(15R) on Crank (58) with Screw (14), Washer (9), Washer (11), Nylon
Nut (16) and Cover with Cap (13). Screw Pedal Tube (15L) on Crank (58) with the same operation.
Attn: The Screw of Pedal separate with L and R mark, Mark "R" should be clockwise, Mark "L" should
be Counter-clockwise.
8
