1.0 Introduction

The Labnet Mini Incubator is a compact general purpose convection incubator capable of uniformly heating samples up to a maximum
of 70°C. The unit comes with a movable shelf and has a door window area so samples can be observed without opening the door
causing heat loss.

2.0 Symbols and Conventions

The electrical warning symbol indicates the presence of a potential hazard which could result in electrical shock.
This symbol indicates a potential risk and alerts you to proceed with caution.
Indicates to take care to avoid coming into contact with a hot surface. Be careful if the unit has been used to heat samples
because the internal components can be extremely hot and can cause burns to uncovered skin. Always check the handle
temperature before changing the platform.

3.0 Safety Information

To ensure safe operation of the unit, please follow the guidelines below, and read this manual in its entirety.
To avoid electrical shock, do not use the incubator near water sources. Be sure that water doesn't get on the device,
especially during the cleaning procedures.
To avoid damage to the instrument, do not expose the incubator to aggressive vapors (e.g., organic solvents).

4 .0 Specifications

Electrical requirements
115V model
230V model
Fuse
Temperature range
Controls
Exterior dimensions (W x L x H)
Chamber dimensions (W x D x H)
Weight
Included accessories
Working environment temperature
Storage environment temperature
Environmental conditions
The Labnet Mini Incubator is designed to be safe at least when operated under the following conditions:
Indoor use

Pollution Degree 2

Inspect the unit and accessories thoroughly upon receipt. If any item is damaged, contact the carrier immediately. The carrier is
responsible for shipping damage. Also verify that all accessories are included and that the unit is in working order before discarding
any shipping packaging.
NOTE: Your satisfaction and safety require a complete understanding of this unit. Read the instructions thoroughly, and be sure all
operators are given adequate training before attempting to put the unit in use. This equipment must be used only for its intended
application; any alterations or modifications will void your warranty and may cause injury.
115V ±10%, 50/60Hz, 0.6A
230V ±10%, 50/60Hz, 0.5A
F250V~1A, 5 × 20 mm
Ambient +5°C to 70°C
Analog, hydraulic
11.2 x 11 x 13.2 in. (28.5 x 28 x 33.5 cm)
19 x 7.9 x 7.9 in. (23 x 20 x 20 cm)
18.4 lbs. (8.3 kg)
Shelf (1)
10°C to 30°C
-20°C to 50°C
≤70% RH, 70 to 106 kPa
