- Page 1 HIGH PERFORMANCE INCUBATORS : 311D, 611D ODELS NSTALLATION AND NSTRUCTION ANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION 1.0 INTRODUCTION SECTION 2.0 WARRANTY SECTION 3.0 SPECIFICATIONS SECTION 4.0 RECEIVING AND INSPECTION SECTION 5.0 INSTALLATION SECTION 6.0 CONTROLS OVERVIEW SECTION 7.0 OPERATION SECTION 8.0 CLEANING AND ROUTINE CARE SECTION 9.0 SERVICE AND TROUBLESHOOTING SECTION 10.0 PARTS LIST WIRE DIAGRAM REV. -
Page 3: Introduction
For applications where the flow of air in the chamber is undesirable, the fan may be switched off. The interiors of the 311D and 611D incubators are constructed of stainless steel. The exteriors are made of cold rolled steel to resist corrosion and provide strength. The door of the incubator consists of two parts. -
Page 4: Warranty
This guarantee is valid only if the unit has been used in accordance with the instructions in this manual and for its intended purpose. Labnet International, Inc. shall not be responsible for consequential damages or damages resulting from the abuse or misuse of this equipment. -
Page 5: Specifications
Section SPECIFICATIONS Temperature Range Ambient +5 to 95C Temperature Uniformity 311D +0.2 @ 37C 611D +0.25 @ 37C Temperature Accuracy +0.2 Temperature Set / Display Digital / digital Temperature Control Microprocessor Overtemperature Safety Independent, settable Interior Outlet 1AMP Door Inner – glass... -
Page 6: Receiving And Inspection
If any, the carrier will arrange for official inspection to substantiate your claim. Return Shipment: Save the shipping crate until you are sure all is well. If for any reason you must return the unit, contact Labnet International, Inc. for authorization and supply the data plate information. -
Page 7: Installation
Section INSTALLATION Local city, county, or other ordinances may govern the use of this equipment. If you have any questions about local requirements, please contact the appropriate local agency. Installation may be performed by the end user. Under normal circumstances this unit is intended for use indoors, at room temperatures between 5... - Page 8 Cleaning: The unit chamber should be cleaned and disinfected before use. Remove all of the interior parts, and clean thoroughly with a disinfectant that is appropriate to your application. DO NOT use chlorine-based bleaches or abrasives as this will damage the chamber interior. Regular periodic cleaning is required.
-
Page 9: Controls Overview
Section CONTROLS OVERVIEW Power Switch: The main power ON/OFF switch controls all power to the unit. It must be on before any systems are operational. The green switch will be lighted when ON. Main Temperature Control: This control consists of the digital display and Up/Down buttons for inputting set point temperatures and calibration. -
Page 10: Operation
Section OPERATION Check power supply against unit serial plate. They must match. Plug service cord into the electrical outlet. Push power switch ON, and turn the Safety Thermostat to its maximum position, clockwise. Set Main Temperature Control: Enter desired set point temperature. To enter set point mode on the control, press either the Up or Down button one time. - Page 11 stable temperature the fan may be turned off.
-
Page 12: Cleaning And Routine Care
Section CLEANING AND ROUTINE CARE Both the interior and exterior of the incubator should be wiped down with a soft cloth periodically to prevent any build-up of dust and grime. Any spills in the incubator should be cleaned immediately. Cleaning may be performed with a soft, damp cloth. -
Page 13: Service And Troubleshooting
Section SERVICE AND TROUBLE-SHOOTING TEMPERATURE Temp-1 Temperature too high- display and reference thermometer don’t match 1/ Controller failed on – call Customer Service. 2/ Wiring error – call Customer Service. Temp-2 Display reads "HI" or "400"+ Probe is unplugged or broken – Call Customer Service Temp-3 Chamber temperature spikes over set point... - Page 14 1/ Safety set too low – see section 7.5. 2/ Controller set too low – see section 7.3. 3/ Unit not recovered from door opening – wait for display to stop changing. 4/ Unit not recovered from power failure or being turned off –...
- Page 15 including motors, arcing relays or radio transmitters. 7/ Bad connection on temperature sensor or faulty sensor – check connectors for continuity and mechanical soundness while watching display for erratic behavior; check sensor and wiring for mechanical damage. 8/ Bad connections– check connectors for mechanical soundness and look for corrosion around terminals or signs of arcing or other visible deterioration.
- Page 16 1/ If shaft spins freely: check connections to motor and check voltage to motor. 2/ If shaft rubs or is frozen, relieve binding and retest. Mech-3 Motor makes noise 1/ If noise is from the motor, tap the top of motor shaft with ball peen hammer.
- Page 17 2/ Develop and follow standard operating procedure for specific application; include definition of cleaning technique and maintenance schedule. If following the troubleshooting suggestions does not solve the problem, contact Labnet International’s Service Department at 888 522-6381, Monday through Friday, 9:00am – 5:00pm, EST.
-
Page 18: Parts List
PARTS LIST Description 120V 220V Blower Motor I-104100 I-210001 Circuit Breaker I-1100505 I-1100505 Convenience Outlet I-100020 I-101483 Door Element I-100019 I-100019 Door Switch I-104103 I-104103 Heating Element I-200114 I-120071 Light Socket I-104098 I-104098 MP Control I-1750692 I-1750693 On / Off Switch I-102025 I-102025 Power Cord...
