Getting Started; Operation; Troubleshooting - Labnet I5110A Instruction Manual

8.0 Getting Started

Thermometer port
Main power switch
Install the shelf at the desired height, shelf edges down. If you intend to place samples on the bottom of the chamber, install the shelf
so that it sits edges down on the chamber bottom, thus creating an air gap between the chamber bottom and your samples.
NOTE: When installing your shelf, remember to leave clearance for the thermometer bulb which will come down from the roof of
the chamber.
Gently insert the thermometer (supplied separately) into the hole in the top of the incubator. NOTE: Inserting or removing the
thermometer too quickly can dislodge the rubber grommet used to hold the thermometer. For maximum accuracy, insert the
thermometer to a point where the thermometer immersion line is just inside the incubator chamber.

9.0 Operation

Push the Power switch to the ON position. The switch should illuminate.
Set the temperature controller to 10. When the thermometer reaches the desired operating temperature, turn the control down until
the heating light turns off. Wait for the temperature to stabilize. Make small adjustments up and down as required until the desired
operating temperature is obtained. Allow the unit to stabilize between each adjustment. Temperature stability is obtained when the
HEATING lamp is going on and off automatically and the temperature remains constant.
Optional: The oven has a port in the back of the unit for passing a power cord out of the rear of the unit. This is for powering a small
piece of equipment (shaker, etc.) in the incubation chamber. To pass a cord through, rotate the inner and outer doors up to reveal the
pass through. Then, slide the end of the power cord through the port. Then, close both doors, resting the cord in the notch.

10.0 Troubleshooting

Should you have a question about the Labnet Mini Incubator or require service for the unit, contact Corning Customer service at
800.492.1110 or 978.442.2200. Do not send a unit for service without first calling to obtain a repair authorization (RA) number. The
unit should be properly packed to avoid damage. Any damage resulting from improper packaging shall be the responsibility of the
user.
Problem
Oven does not heat
Cause
Power connection
Fuse
Temperature is set too low
Heating indicator light
Heater control knob
Solution
Check power connection.
Check fuse.
Adjust temperature control knob higher.
Instruction Manual | 3
