Installation Instructions

Ducting Options

spaces between walls, crawl spaces, ceilings, attics, or garages.
All exhaust must be ducted to the outside, unless using the
►
Use single wall rigid metal ductwork only.
►
Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct
Tape.
Roof pitch w/
flashing & cap
10
WARNING
Fire Hazard: NEVER exhaust air or terminate ductwork into
recirculating option.
Soffit or crawl space
Rear ducting
Cypress Use, Care, and Installation Guide
C Y P R E S S
Side wall cap
w/ gravity damper
P R O
WA L L
