8.4.6 Image Savings

This tool is used to save image caches into the device, and saved images can be downloaded to the
local or be exported to the test library for the device debugging. Refer to Section Image Saving
Management for details.
Image Source: By default, the image source is the images acquired by the device.
Input Status: Click
linked data result.
After Image Source and Input Status are entered, you should select the Save Mode, Picture
Format (RAW, BMP, JPG), and Image Saving according to actual demands.
Note
Save Mode has 2 types, including stop_save and cover_save. If you select stop_save, images will
not be saved when max. save number is reached. If cover_save is selected, current images will
be saved but previous saved image will be covered.
You can enable Frame No., Trigger No., and Result to save the current image's related information.
Start Tag and End Tag allows you to set the start and end characters of the image name, and
uppercase and lowercase letters, digits, as well as ! @ # ^ & () - _ = + . , ; ' are allowed.
Delimiter refers to the content you used to separate the image name, and uppercase and lowercase
letters, digits, as well as ! @ # ^ & () - _ = + . , ; ' are allowed.
SC7000 Series Smart Camera User Manual
to link the previous module status, and image saving is decided by the
