7. Assembly of Optional parts

Bracket
Groove
Bottom
of the body
Bracket B
1)
Product
Bracket A
2)
Set screw
(2 pcs.)
-12-
Mounting of bracket A
Insert bracket A from the front side of the product
so that the finger of the bracket A engages with
the groove and the bottom of the body.
(see drawing on the left)
Finger
Mounting of bracket B
Fix the bracket B with the set screw (2 pcs.)
included in the package. Refer to the table
below for the tightening torque.
Model No. Tools
AFF50
Phillips
screwdriver(+)
AFF60
Tightening torque
1.5±0.2 Nm
