INSTALLATION INSTRUCTION
If you have any questions, please feel free to contact our customer support
before returning.
Safety Caution
Please read this instruction carefully before installation. If you do not understand these
instructions or have doubts about the safety of the installation, assembly or use of this
product, please contact us.
● This product is designed for use in wood stud or solid concrete wall.
- DO NOT install into drywall alone.
● The wall must be capable of supporting five times the weight of the TV and mount combined.
● Incorrect installation may result in product damage/property damage or body injury.
We shall bear no responsibility for any damage or injury resulted from incorrect installation,
incorrect assembly or misuse.
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are
missing or damaged, do not return the damaged item to your dealer; please contact our
customer service team. Never use damaged parts!
Must Check Before Getting Started
Minimum VESA Pattern (W × H):
75mm × 75mm / 3 in × 3 in
H
Maximum VESA Pattern (W × H):
400mm × 400mm / 16 in × 16 in
Load
Capacity
MAX:
88 lbs (40 kg)
Verify Your Wall Construction
<5/8"(16mm)
Min. 4"
CAUTION:
(102mm)
Avoid potential personal injuries and property damage!
Drywall covering the wall must not exceed 5/8 in. (16 mm).
Min. 2"
Perfect!
Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm)
(51mm)
actual 1 ½ x 3 ½ in. (38 x 89 mm).
Wall with wood studs
Min. 8"
(203mm)
CAUTION:
Avoid potential personal injuries and property damage!
Mount the wall plate assembly directly onto the concrete
Perfect!
surface (no surface covering).
CAUTION:
DO NOT install into drywall alone.
1
Product Dimensions
YZ2307_US2.0
Supplied Parts and Hardware
Arm and Wall Plate
VESA Plate
0
01
×1
Lag Bolt
Open-end
Carriage
Flange Nut
ST8x65mm
Wrench
Bolt
A
x3
B
x1
C
x4
D
x4
TV
Philips Screws
Philips Screws Philips Screws
M4 x 12mm
M6 x 15mm
M8 x 25mm
M4 x 30mm
M6 x 30mm
M8 x 45mm
×4
×4
×4
×4
×4
×4
MA
MB
MC
Velcro Cable Ties
Bubble Level
×1
T1
NOTE: Not all parts and hardware included will be used.
Extra Tools You Need (Not Supplied)
For
For
Wood Studs
Concrete Wall
2M
Ф7/32"
Ф3/8"
(Ф5.5mm)
(Ф10mm)
Stud
Awl
Wood
Masonry
Hammer
Band
Pencil
Finder
Drill Bit
Drill Bit
Tape
2
1
Attach Brackets to TV
1-1
Select VESA Plate Configuration
Swivel ±90°
Measure the width and the height of the square or rectangle formed from the VESA
holes pattern. Select the configuration to use based on the measurement from TV.
+5°
Tilt
W
-13°
H
200mm
100mm
75mm
A
for VESA Hole Pattern:
75x75mm, 100x100mm, 100x200mm,
200x100mm, 200x200mm.
Extenders
02
×1
03
×4
200mm
Allen key
E
x1
B
for VESA Hole Pattern:
200x300mm
Spacers
Washers
Spacers
Ф6mm
H10mm
H5mm
M4-5-6
1-2
Assemble VESA Plate and Extenders (When VESA > 200mm)
×8
×4
×8
If your TV hole pattern is greater than 200×200mm, attach extenders (03) to VESA
MD
ME
MF
plate (02) using bolts (C) and nuts (D).
×3
T2
1/2"
(13mm)
Electrodrill
Socket
Screwdriver
Wrench
1
1-3
Select TV Screws
VESA Pattern
VESA Pattern
Configuration
Configuration
(WxH)
(WxH)
75mm x 75mm
A
300mm x 200mm
C
100mm x 100mm
A
400mm x 200mm
C
100mm x 200mm
A
400mm x 300mm
D
200mm x 100mm
A
300mm x 250mm
D
200mm x 200mm
A
300mm x 300mm
E
200mm x 300mm
B
400mm x 400mm
E
400mm
300mm
Too Short
Need Spacer?
C
for VESA Hole Pattern:
300x200mm, 400x200mm.
Yes, choose the appropriate screws, washers,and spacers for your TV.
400mm
300mm
01
D
for VESA Hole Pattern:
400x300mm, 300x250mm.
For more spacing
between bracket
400mm
300mm
No, just choose the screws, washers.
E
for VESA Hole Pattern:
300x300mm, 400x400mm.
Tighten
Not for M8 Screws
MD
May be needed
3
(Continued)
M8
M6
M4
Too Long
Not Vertical
Correct
Correct
Long Screw
Washer
Spacer
Bracket
TV back
02
03
04
For protruded
To avoid the
For counterbore
back TV
of TV
blocked input
and TV
Bracket
Short Screw
Washer
TV back
Do not tighten the screws excessively or tighten them by
using the Electrodrill, or your TV might be damaged.
MC
MA
MB
UP
ME
MF
4
