Tape Measure
Valance
If Ordered
x2
Bracket
*Note: Valance Returns are
optional
STEP 1 - VALANCE INSTALLATION (If Ordered)
NOTES
Valance must be installed as a first step before the Roller Shade. If you didn't order a Valance proceed to Step 2.
•
A - For INSIDE mount, divide valance width into
thirds and mark 2 screw holes on the underside
of the valance. Drill through cover to secure the
valance in place.
1/3
distance
©2025 Select Blinds V6-032025
REQUIRED TOOLS FOR INSTALLATION
OPEN ROLL
Level
COMES WITH YOUR ORDER
Shade Brackets
Control-end
Idler-end
Idler-end
Bracket
Bracket
Bracket
ROLLER SHADE INSTRUCTIONS
1/3
distance
Open Roll Installation Instructions
Power Drill / Screwdriver
Screws
Clutch-end
Bracket
B - For OUTSIDE mount, mark the location of the
shade mounting brackets with a pencil (see step 2),
and measure 1/2" from the top of the bracket to note
the location of the Valance bracket. Valance brackets
should be installed 5"-8" from each end of the valance.
Additional bracket(s) may be necessary and should
be evenly spaced between the two ends brackets if
required.
5"-8"
1/2"
Pencil
Roller Shade
Idler side
Control Side
5"-8"
Open Roll Installation Instructions
|
1
Advertisement
Table of Contents
Related Manuals for SelectBlinds OPEN ROLL
Summary of Contents for SelectBlinds OPEN ROLL
- Page 1 Open Roll Installation Instructions REQUIRED TOOLS FOR INSTALLATION OPEN ROLL Tape Measure Level Pencil Power Drill / Screwdriver COMES WITH YOUR ORDER Valance Shade Brackets Screws Roller Shade If Ordered Idler side Control Side Control-end Clutch-end Idler-end Idler-end Bracket Bracket...
-
Page 2: Step 2 - Bracket Installation
Open Roll Installation Instructions STEP 2 - BRACKET INSTALLATION NOTES • Before fully installing your brackets, note the difference Ordered Shade Width between the control and idler brackets. • In order to ensure the shade does not fall out of the brackets, it is critical that the idler pin is securely compressed by at least 1/4”... - Page 3 Open Roll Installation Instructions NOTES • Ensure fabric rolls in the direction you specified (regular or reverse roll) • Your control side depends on what you specified in your order Regular Roll Reverse Roll Fabric rolls off the back of the...
- Page 4 Open Roll Installation Instructions STEP 4 - TWO ON ONE SHADES Intermediate Bracket Intermediate Bracket Idler End - Left Shade Idler End - Right Shade Using a steel measuring tape, measure the distance from the outside edge of each control-end bracket according to the ordered shade width.
-
Page 5: Maintenance And Care
Open Roll Installation Instructions FABRIC ADJUSTMENT MAINTENANCE & CARE If telescoping occurs, roll your shade down a few inches Fabrics can be periodically dusted using a soft cloth, pass the window sill and place tape on the fabric as feather duster, or vacuum cleaner with brush attachment. -
Page 6: Required Tools For Installation
Cassette Installation Instructions REQUIRED TOOLS FOR INSTALLATION CASSETTE, MODELS S-300 | S-325 | V-80 Tape Measure Level Pencil Power Drill / Screwdriver COMES WITH YOUR ORDER S-300 Brackets S-325 / V-80 Brackets Screws Applications Roller Shades High-Lite Shades Sheer Horizontal Shade Width (“) # of Brackets Supplied 0 - 60 60 - 84... - Page 7 Cassette Installation Instructions S-300 Cassette S-325 Cassette V-80 Cassette 2 7/8” H x 3 1/8” W 3 1/8” H x 3 1/2” W 3 3/8” H x 3 1/8” W STEP 2 - MOUNTING THE SHADE (S-300 | S-325) STEP 2 - MOUNTING THE SHADE (V-80) Snap in Snap in place here...
- Page 8 Cassette Installation Instructions STEP 4 - AFFIX U-CLIP TO WALL (CHAINGUARD ONLY) CHILD/SAFETY CHAIN TENSIONER INSTALLATION If preferred, the U-Clip can be affixed to the wall to prevent the chain from swaying. Position the U-Clip so it does not interfere with the travel of the shade. Chain should be tight, but not under stress when U-Clip is affixed to the wall. To do so, remove the screw at the front of the U-Clip and gently pry the cover off.
- Page 9 Deluxe Valance Installation Instructions VALANCE ASSEMBLY VALANCE ASSEMBLY The valance is to be mounted after the total installation. The valance is to be mounted after the total installation. VALANCE ASSEMBLY VALANCE ASSEMBLY THE VALANCE IS TO BE MOUNTED AFTER THE TOTAL INSTALLATION Attach the corner pieces into the back slot of the Attach the corner pieces into the back slot of the The valance is to be mounted after the total installation.
-
Page 10: How To Operate
Cordless Operating Instructions HOW TO OPERATE CAUTION: Do not lower the shade past the ordered length because damage may occur to the shade. SPRINGDRIVE To lower your shade, grasp the bottom bar (handle) from the centre-point and gently pull the shade down to desired position. To raise your shade, give a slight pull on bottom bar handle, and the shade will raise automatically in a gradual and controlled motion, stopping at the top. - Page 11 If your shade is not performing as desired, it is likely because the brackets are installed too close together, causing too much friction and pressure on the internal spring. A proper installation (for Fascia or Open Roll shades only) will result in a ¼”...
- Page 12 BASICS Motor User Guide AM25 AM22 Channel LED Lights ON/OFF Toggle I. Operation Instruction Remote battery: CR2032 1. Power ON/OFF OR Sleep/Wake 2. Pairing Remote AM25 Model only Ensure toggle is in ON Press P1 button on motor To wake, press P1 Select channel on your Press and hold UP position.
-
Page 13: Troubleshooting
9. Adding Remotes or Channels 10. Deleting Remotes or Channels Select remote/channel to be Press and hold S1 for 1 second On current remote/channel, Select new remote/channel deleted and press and hold and the motor will jog to press and hold “STOP” until and press “UP”. -
Page 14: Smart Controller
SMART CONTROLLER ENGLISH SETUP CODE System requirements CODE DE CONFIGURATION • A strong WiFi signal (3 bars or more) in the location where you will setup your Smart Controller. • The Smart Controller only supports 2.4GHz WiFi (IEEE 802 11b/g/n), not 5GHz. WiFi security needs to be set to WPA-PSK or SBCAN WPA2-PSK.
