Menu bar The lower part of the screen shows a menu bar with icons:
These illustrate the function of each Function key. Please note that the function of
each key changes depending on the selected menu. Refer to "Main menu options"
on page 41 for more information.
In case of problems, a message appears in the screen, just below the speed bar.
Warnings
and
If there is more than one message or warning, the message bar changes every few
messages
seconds to present messages consecutively. Refer to "Warnings and errors
overview" on page 58 for more information.

3.2.3 Function keys

The User console has 5 function keys:
The function of each of these keys depends on the selected menu and is identified by an icon
at the bottom of the screen. For the Main screen, this is:
• If a key is not linked to a particular function in a menu, no icon is displayed.
• F3 functions as the Hold key in the main menu. When driving the vehicle and using
WEED-IT, press the key to temporarily disable (Hold) the WEED-IT system, for example
when turning on the headlands.
• In other menus, the F3 function key is mostly used to confirm a setting.

3.2.4 Navigation keys

The navigation keys consist of 4 arrow keys (Left, Right, Up, Down) and a Menu key in the
middle:
• Use the arrow keys to select a value or to move through items in a menu.
• Press to select a menu.
• Press repeatedly to browse through available menus.
WEED-IT Quadro | User Manual - BT-UMWEEDQ-C | 23 / 122
