Croplands WEED-IT QUADRO User Manual page 114

The spray width nozzle is the spray width of one nozzle at the soil surface, and is important for an optimal spot spray
result. The following table indicates in green what configurations are best suitable for spot spraying. Each detection
channel is 25 cm wide, and so the spray width must be at least 25 cm.
Note that the nozzle height is configured in the WEED-IT by your dealer and that the spray boom must stay at this nozzle
height to ensure the weed is detected and hit with herbicide optimally.
In the table spray widths up to 45 cm (so with 10 cm overlap at both sides) are indicated as suitable. However, rough
conditions, such as uneven terrain or unstable spray booms may require a larger spray width.
Top angle (°)
20 30
15 5 8
20 7 11
25 9 13
30 11 16
35 13 19
40 15 22
45 17 25
50 19 28
55 21 31
60 23 35
65 25 38
73 30 44
80 34 50
85 37 55
90 40 60
95 44 65
100 48 72
110 57 86
120 69 104
130 86 129
140 110 165
150 149 224
114 / 122 | WEED-IT Quadro | User Manual - BT-UMWEEDQ-C
Spot Spraying formulas (2)
Spray width with diverse nozzle heights (cm)
40 50 55 60
11 13 14 16
14 18 19 21
18 22 24 27
21 27 29 32
25 32 35 38
29 36 40 44
33 41 46 50
37 47 51 56
42 52 57 62
46 58 64 69
51 64 70 76
59 74 81 89
67 84 92 101
73 92 101 110
80 100 110 120
87 109 120 131
95 119 131 143
114 143 157 171
139 173 191 208
172 214 236 257
220 275 302 330
299 373 411 448
65 70 75 80
17 18 20 21
23 25 26 28
29 31 33 35
35 38 40 43
41 44 47 50
47 51 55 58
54 58 62 66
61 65 70 75
68 73 78 83
75 81 87 92
83 89 96 102
96 104 111 118
109 117 126 134
119 128 137 147
130 140 150 160
142 153 164 175
155 167 179 191
186 200 214 229
225 242 260 277
279 300 322 343
357 385 412 440
485 522 560 597
85 90 95 100
22 24 25 26
30 32 34 35
38 40 42 44
46 48 51 54
54 57 60 63
62 66 69 73
70 75 79 83
79 84 89 93
88 94 99 104
98 104 110 115
108 115 121 127
126 133 141 148
143 151 159 168
156 165 174 183
170 180 190 200
186 196 207 218
203 215 226 238
243 257 271 286
294 312 329 346
365 386 407 429
467 495 522 549
634 672 709 746
