Hardware Reference Diagram:
Specifications subject to change without prior notice.
M6x15 Blot 28pcs
D1
ST4.0x10 Screw 4pcs
M5 Nuts 2pcs
M4x10 Blot 4pcs
M5x10 Blot 2pcs
Locknut 2pcs
D1
D5
D10
D4
D8
D3
M5x15 Blot 2pcs
M4 Nuts 4pcs
Washers 2pcs
Hose Hook 1pc
D2
D9
D13
Shelf Spacer 6pcs
ST4.8x15 Screw 6pcs
ST4.0x15 Screw 4pcs
D12
D7
D11
D6
