19
C6
Attach the Side Burner Shelf (C6) to the left front and left rear legs using M6x15 Bolts
(D1x4pcs).
20
C9
Remove the mounting screws from Side Burner Valve / Hose Assembly (C9) and secure the
side burner valve to the side burner shelf using those 2 screws.
Assemble the Side Burner Knob (C4) onto the side burner valve.
D1
C4
14
