Parts Identification - Backyard Discovery STRATFORD Assembly Manual

Owner's Manual
Metal Components (Not to Scale)
A1
POST - A4M01565
(2)
6"x6"x88" (152x152x2235)
A2
POST - A4M01566
(2)
6"x6"x88" (152x152x2235)
B1
JOIST END - A4M01610
(2)
1 3/8"x5 1/4"x60 1/2" (36x134x1537)
B2
JOIST END - A4M01611
(2)
1 3/8"x5 1/4"x60 1/2" (36x134x1537)
B3
JOIST - A4M01596
(2)
1 3/8"x5 1/4"x71 1/4" (36x134x1811)
C1
JOIST END - A4M01612
(2)
1 3/8"x5 1/4"x72 1/8" (36x134x1831)
C2
JOIST END - A4M01613
(2)
1 3/8"x5 1/4"x72 1/8" (36x134x1831)
D1
JOIST END - A4M01614
(8)
1 5/8"x3 1/8"x72 1/8" (40x80x1831)
D2
JOIST END - A4M01615
(24)
1 5/8"x3 1/8"x72 1/8" (40x80x1831)
