12x10 STRATFORD, ASHFORD, HAWTHORNE PERGOLA
Model #'s
2105089, 2105096, 2105102
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT YOU NEED
Made in China | INS-2105089, 2105096, 2105102-A-12X10 PERGOLA-ENG 3-3-21
2105089 STRATFORD
(BLACK)
2105102 HAWTHORNE
average 2 person assembly time
assembly time may vary based on skill level
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddiscovery.com
TO ORDER REPLACEMENT PARTS.
Owner's Manual & Assembly Instructions
2105096 ASHFORD
(BROWN)
(WHITE)
MANUFACTURED BY:
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
800-856-4445

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STRATFORD 2105089 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Discovery STRATFORD 2105089

Summary of Contents for Backyard Discovery STRATFORD 2105089

  • Page 1 12x10 STRATFORD, ASHFORD, HAWTHORNE PERGOLA MANUFACTURED BY: Backyard Discovery 3305 Airport Drive Model #'s Pittsburg, KS 66762 Owner's Manual & Assembly Instructions 800-856-4445 2105089, 2105096, 2105102 2105089 STRATFORD 2105096 ASHFORD (BLACK) (BROWN) 2105102 HAWTHORNE (WHITE) average 2 person assembly time...
  • Page 2 INSTALLATION SERVICES AVAILABLE! Need a helping hand? Let our team of professionals handle the installation for you! *Installation services are only available to U.S. customers. With Go Con gure, we bring you 18 years of experience right to your doorstep. We service a wide array of indoor and outdoor recreation products that most consumers don’t have the time or ability to deliver &...
  • Page 3 Owner’s Manual Please Read This Before Starting Assembly MISSING A PART? CALL US BEFORE GOING BACK TO THE STORE The store where you made your purchase does not stock parts for this item. If you have assembly questions or you are missing or have damaged parts, please call 1-800-856-4445 you can also visit www.backyarddiscovery.com...

  • Page 4: Limited Warranty

    Backyard Discovery Wood Patio Structure Backyard Discovery warrants this wood patio product to be free from defects in materials and workmanship for a period of two (2) year from the original date of purchase. All wood carries a five (5) year warranty against rot and decay from the original purchase date.
  • Page 5 • Permanent structures may require a building paint meeting the requirements of Title 16 CRF Part 1303. • Touch up paint is available through Backyard Discovery. permit. As the purchaser and or installer of this Please have the product number tag available for product you are advised to consult local planning, reference for customer support.

  • Page 6: Tools Required

    Assembly Tips & Tools Required Owner’s Manual ASSEMBLY TIP: Keep and eye out for these boxes which will contain helpful pictures and information making the assembly process as quick and painless as possible. Sorting Parts When removing the parts from the boxes we recommend arranging them by part number before you begin assembly.
  • Page 7 Basic Setup Dimensions & Assembly Notes Owner's Manual It is critically important that you start with square and level footings, concrete pad or deck to attach your structure • Pay close attention to the items needed for each step. Make sure you are using the correct hardware for each step.

  • Page 8: Parts Identification

    Owner's Manual Parts Identification Metal Components (Not to Scale) POST - A4M01260 6"x6"x88" (152x152x2235) POST - A4M01261 6"x6"x88" (152x152x2235) JOIST END - A4M01287 1 3/8"x5 1/4"x72 1/8" (36x134x1833) JOIST END - A4M01288 1 3/8"x5 1/4"x72 1/8" (36x134x1833) JOIST END - A4M01282 1 3/8"x5 1/4"x60 1/8"...
  • Page 9 Owner's Manual Parts Identification Metal Components (Not to Scale) SPLICE BRACKET - A4M01270 SPLICE BRACKET - A4M01271 SPLICE BRACKET - A4M01269 (12) 1 1/4"x5 1/8"x15 3/4" (33x131x400) 1 1/2"x3"x15 3/4" (37x77x400) 1 1/4"x5 1/8"x19 5/8" (33x131x500) PURLIN END - A4M01289 (10) 3/4"x1 5/8"x77 5/8"...

  • Page 10: Hardware Components

    Owner's Manual Parts Identification Hardware Components H101040 HEX PAN HEAD (186) M6x1x20 H101053 STEEL WASHER H101054 SEALANT WASHER (250) (250) 6x20 HEX PAN HEAD H101041 M6x1x40 (42) HEX PAN HEAD H101042 M6x1x100 (26) H101052 ALLEN BIT HEX SOCKET SCREW H101043 M6x1x20 (34) H101051...
  • Page 11 Owner's Manual Parts Identification Accessory Components (Not to Scale) POST FOOT PLATE - A4M01278 POST FOOT - A4M01279 FOOT PLASTIC PLATE - A6P00464 2 1/8"x8 3/8"x8 3/8" (54x213x213) 2 5/8"x9 7/8"x9 7/8" (68x250x250) 3/8"x8 1/8"x8 1/8" (11x207x207) 2-WAY SQUARE PLUG- A6P00465 (10) 3/4"x1 5/8"x2"...
  • Page 12 PERGOLA ASSEMBLY STEP 1 JOIST END - A4M01282 HEX PAN HEAD H101040 H101053 STEEL WASHER M6x1x20 (16) 1 3/8"x5 1/4"x60 1/8" (36x134x1526) (16) 6x20 SHORT ANGLE BRACE - A4M01275 SPLICE BRACKET - A4M01270 H101054 SEALANT WASHER 1 1/8"x4"x14" (30x101x355) 1 1/4"x5 1/8"x15 3/4" (33x131x400) (16)
  • Page 13 PERGOLA ASSEMBLY STEP 2 H101040 HEX PAN HEAD H101053 STEEL WASHER (16) M6x1x20 (16) 6x20 JOIST END - A4M01283 SHORT ANGLE BRACE - A4M01276 1 3/8"x5 1/4"x60 1/8" (36x134x1526) 1 1/8"x4"x14" (30x101x355) H101054 SEALANT WASHER (16)
  • Page 14 PERGOLA ASSEMBLY STEP 3 POST - A4M01260 POST - A4M01261 HEX PAN HEAD HEX SOCKET SCREW H101040 H101043 6"x6"x88" (152x152x2235) 6"x6"x88" (152x152x2235) M6x1x20 M6x1x20 (16) JOIST ASSEMBLY - FROM PREVIOUS STEPS H101054 H101053 SEALANT WASHER STEEL WASHER 6x20...
  • Page 15 PERGOLA ASSEMBLY STEP 4 HEX PAN HEAD H101040 H101053 STEEL WASHER M6x1x20 6x20 POST FOOT PLATE - A4M01278 POST FOOT - A4M01279 2 1/8"x8 3/8"x8 3/8" (54x213x213) 2 5/8"x9 7/8"x9 7/8" (68x250x250) H101054 SEALANT WASHER...
  • Page 16 PERGOLA ASSEMBLY STEP 5 HEX PAN HEAD JOIST END - A4M01287 H101040 LONG ANGLE BRACE - A4M01273 H101053 STEEL WASHER M6x1x20 (16) 1 3/8"x5 1/4"x72 1/8" (36x134x1833) 1 1/8"x4"x21 1/2" (30x101x546) (16) 6x20 SPLICE BRACKET - A4M01269 1 1/4"x5 1/8"x19 5/8" (33x131x500) H101054 SEALANT WASHER (16)
  • Page 17 PERGOLA ASSEMBLY STEP 6 HEX PAN HEAD H101040 H101053 STEEL WASHER M6x1x20 (16) (16) 6x20 JOIST END - A4M01288 LONG ANGLE BRACE - A4M01274 1 3/8"x5 1/4"x72 1/8" (36x134x1833) 1 1/8"x4"x21 1/2" (30x101x546) H101054 SEALANT WASHER (16)
  • Page 18 PERGOLA ASSEMBLY STEP 7 HEX PAN HEAD HEX SOCKET SCREW H101040 H101043 JOIST ASSEMBLY - FROM PREVIOUS STEPS M6x1x20 M6x1x20 (16) H101054 H101053 SEALANT WASHER STEEL WASHER 6x20 UPRIGHT ASSEMBLY - FROM PREVIOUS STEPS...
  • Page 19 PERGOLA ASSEMBLY STEP 8 FOOT PLASTIC PLATE - A6P00464 3/8"x8 1/8"x8 1/8" (11x207x207)
  • Page 20 PERGOLA ASSEMBLY STEP 9 HEX PAN HEAD H101040 H101053 STEEL WASHER M6x1x20 (16) (16) 6x20 JOIST END - A4M01284 SPLICE BRACKET - A4M01271 1 5/8"x3 1/8"x60 1/8" (40x80x1526) 1 1/2"x3"x15 3/4" (37x77x400) H101054 SEALANT WASHER (16)
  • Page 21 PERGOLA ASSEMBLY STEP 10 HEX PAN HEAD H101040 H101053 STEEL WASHER M6x1x20 (16) (16) 6x20 JOIST END - A4M01284 1 5/8"x3 1/8"x60 1/8" (40x80x1526) H101054 SEALANT WASHER (16)
  • Page 22 PERGOLA ASSEMBLY STEP 11 H101042 HEX PAN HEAD H101053 STEEL WASHER M6x1x100 6x20 JOIST ASSEMBLY - FROM PREVIOUS STEPS H101054 SEALANT WASHER...
  • Page 23 PERGOLA ASSEMBLY STEP 12 HEX PAN HEAD H101040 H101053 STEEL WASHER M6x1x20 (32) (32) 6x20 JOIST END - A4M01285 SPLICE BRACKET - A4M01271 1 5/8"x3 1/8"x60 1/8" (40x80x1526) 1 1/2"x3"x15 3/4" (37x77x400) H101054 SEALANT WASHER (32)
  • Page 24 PERGOLA ASSEMBLY STEP 13 HEX PAN HEAD H101040 H101053 STEEL WASHER M6x1x20 (32) (32) 6x20 JOIST END - A4M01285 1 5/8"x3 1/8"x60 1/8" (40x80x1526) H101054 SEALANT WASHER (32)
  • Page 25 PERGOLA ASSEMBLY STEP 14 H101042 HEX PAN HEAD (16) M6x1x100 H101053 STEEL WASHER (16) 6x20 JOIST ASSEMBLY - FROM PREVIOUS STEPS H101054 SEALANT WASHER (16)
  • Page 26 PERGOLA ASSEMBLY STEP 15 PURLIN END - A4M01290 (10) 2-WAY SQUARE PLUG- A6P00465 3/4"x1 5/8"x66 7/8" (20x40x1698) (10) 3/4"x1 5/8"x2" (20x40x52)
  • Page 27 PERGOLA ASSEMBLY STEP 16 HEX PAN HEAD H101041 H101053 STEEL WASHER M6x1x40 (20) (20) 6x20 PURLIN ASSEMBLY - FROM PREVIOUS STEPS (10) H101054 SEALANT WASHER (20)
  • Page 28 PERGOLA ASSEMBLY STEP 17 HEX PAN HEAD H101041 H101053 STEEL WASHER M6x1x40 (20) (20) 6x20 PURLIN END - A4M01289 (10) 3/4"x1 5/8"x77 5/8" (20x40x1972) H101054 SEALANT WASHER (20)
  • Page 29 PERGOLA ASSEMBLY STEP 18 HOLE COVER - A4M01352 (32)

  • Page 30: Electrical Enclosure

    ELECTRICAL ENCLOSURE FOR ELECTRICAL ENCLOSURE INSTALLATION REFER TO ASSEMBLY INSTRUCTIONS THAT COMES PACKAGED WITH THE ELECTRICAL ENCLOSURE KIT. INSTALL ON ANY POST THAT IS DESIRED. FOLLOW DIRECTIONS FOR PROPER INSTALLATION.
