Backyard Discovery STRATFORD Assembly Manual page 10

PERGOLA ASSEMBLY
C1
JOIST END - A4M01612
(2)
1 3/8"x5 1/4"x72 1/8" (36x134x1831)
J2
SPLICE BRACKET - A4M01270
(2)
1 1/4"x5 1/8"x15 3/4" (33x131x400)
F3
SHORT ANGLE BRACE - A4M01275
(2)
1 1/8"x4"x14" (30x101x355)
10
STEP 1
H101101 TORX PAN HEAD
1/4-20x3/4"
(16)
H101054
SEALANT WASHER
(16)
H101053
STEEL WASHER
6x20
(16)
