OWNER'S MANUAL - BASIC SETUP DIMENSIONS & ASSEMBLY NOTES It is critically important that you start with square and level footings, concrete pad or deck to attach your structure. • Pay close attention to the items needed for each step. Make sure you are using the correct hardware for each step.
Page 7
OWNER'S MANUAL - PARTS IDENTIFICATION HARDWARE COMPONENTS H101202 | TORX PAN HEAD 1/4-20x3/4 ASSY (x118) | 1/4-20x3/4 ASSY H100474 | WASHER FLAT H100497 | WASHER FLAT | 9x19 BLK | 17x30 BLK (x5) (x12) H101101 | TORX PAN HEAD (x1) | 1/4-20x3/4"...
Page 8
OWNER'S MANUAL - PARTS IDENTIFICATION HARDWARE COMPONENTS H100147 | TORX BIT | RIGHT ANGLE H101114 (x1) | T-30 | DRILL ADAPTER (x1) H101100 | MAGNETIC DRIVER H101106 SOCKET DRIVER (x1) (x1) H100114 | TORX BIT (x1) | T-30...
Page 9
PRE-ASSEMBLY STEP 1 - SORTING PARTS It is critical for ease of assembly that you take the time to sort and organize the parts and hardware. METAL PARTS: • Organize metal parts by the three-digit, alpha-numeric number stamped on each part (ex. P01). •...
Page 10
PRE-ASSEMBLY STEP 2 - TOOLS REQUIRED Drill Attachments: Phillips Head Open End Wrench 7/16" 1/8", 3/16", 3/8" & 7/16" Drill Bits 3/8" Drive Ratchet, 1/2" & 7/16" STD Sockets 1/2" & 7/16" Deep Sockets Phillips Screw Driver Cordless Drill or Electric Drill Rubber Mallet - Claw Hammer...
Page 11
PRE-ASSEMBLY STEP 3 - CHOOSE YOUR ASSEMBLY METHOD There are several types of assembly instructions available to you. 1. Printed Assembly Manual included with your set 2. BILT APP - 3D interactive instructions 3. Combination of the Printed Manual and BILT APP (Note: Step numbers can differ between the two methods)
Page 12
Determine which wall attachment type works best for your application. If unknown consult a licensed contractor. The recommended hardware below is provided. Backyard Discovery does not assume responsibility for any damages to your house. H101310 ATTACHING TO WALL WITH LAG SCREWS...
Page 13
STEP 1 - WALL BRACKET LOCATION LAYOUT 1. DRAW A STRAIGHT LINE 2438MM 2. ALIGN THE BOTTOM OF T02 WITH THE 3. DRAW 6 CIRCLES ACCORDING TO HOLES OFF THE GROUND. STRAIGHT LINE AND KEEP IT LEVEL BY IN T02. USING A 24"...
PowerPort™ 9205413 ELECTRICAL ENCLOSURE (x1) FOR POWERPORT INSTALLATION REFER TO ASSEMBLY INSTRUCTIONS THAT COME PACKAGED WITH THE POWERPORT KIT. INSTALL ON ANY EXTERIOR POST THAT IS DESIRED. FOLLOW DIRECTIONS FOR PROPER INSTALLATION.
