Versa-Lcd Keypad; Versa-Lcdm Keypad; Versa-Lcdr Keypad - Satel VERSA Plus LTE Installer Manual

36
Text messages ....................................................................................................................... 64
Email addresses for messaging ............................................................................................... 8
Users ...................................................................................................................................... 30
Timers ...................................................................................................................................... 4
Event log ............................................................................................................................ 2047
Security grade according to EN50131 .......................................................................... Grade 2
Environmental class according to EN50130-5 ......................................................................... II
Operating temperature range .................................................................................. -10...+55°C
Maximum humidity .......................................................................................................... 93±3%
Electronics board dimensions ............................................................................. 173 x 105 mm
Enclosure dimensions ............................................................................... 266 x 286 x 100 mm
Weight (incl. enclosure and accessories) ........................................................................ 1250 g
7.2

VERSA-LCD keypad

Supply voltage .................................................................................................... 12 VDC ±15%
Standby current consumption
Maximum current consumption
Environmental class according to EN50130-5 ......................................................................... II
Operating temperature range .................................................................................. -10...+55°C
Maximum humidity .......................................................................................................... 93±3%
Enclosure dimensions ............................................................................. 114.5 x 95 x 22.5 mm
Weight ............................................................................................................................... 123 g
7.3

VERSA-LCDM keypad

Supply voltage .................................................................................................... 12 VDC ±15%
Standby current consumption ..........................................................................................50 mA
Maximum current consumption ........................................................................................60 mA
Security grade according to EN50131 .......................................................................... Grade 2
Environmental class according to EN50130-5 ......................................................................... II
Operating temperature range .................................................................................. -10...+55°C
Maximum humidity .......................................................................................................... 93±3%
Enclosure dimensions ................................................................................. 139 x 124 x 22 mm
Weight ............................................................................................................................... 236 g
7.4

VERSA-LCDR keypad

Supply voltage .................................................................................................... 12 VDC ±15%
Standby current consumption ..........................................................................................30 mA
Maximum current consumption ........................................................................................65 mA
Security grade according to EN50131 .......................................................................... Grade 2
Environmental class according to EN50130-5 ......................................................................... II
Operating temperature range .................................................................................. -10...+55°C
Maximum humidity .......................................................................................................... 93±3%
Enclosure dimensions ................................................................................. 139 x 124 x 22 mm
Weight ............................................................................................................................... 240 g
VERSA Plus LTE
VERSA-LCD-GR ..................................36 mA
VERSA-LCD-BL ...................................40 mA
VERSA-LCD-GR ................................ 110 mA
VERSA-LCD-BL ................................. 130 mA
SATEL
