Satel Versa Plus User Manual
Hide thumbs Also See for Versa Plus:
Table of Contents

Advertisement

1471
USER
MANUAL
SATEL sp. z o.o.
ul. Budowlanych 66
80-298 Gdańsk
POLAND
tel. 58 320 94 00
www.satel.eu
versa_plus_u_en 04/16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Versa Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Satel Versa Plus

  • Page 1 1471 USER MANUAL SATEL sp. z o.o. ul. Budowlanych 66 80-298 Gdańsk POLAND tel. 58 320 94 00 www.satel.eu versa_plus_u_en 04/16...
  • Page 2 (the alarm will be signaled optically and acoustically, appropriate services will be notified, etc.), which may deter the potential burglars. SATEL's goal is to continually upgrade the quality of its products, which may result in some changes of their technical specifications and firmware. The current information on the introduced modifications is available on our website.
  • Page 3: Table Of Contents

    CONTENTS Introduction........................3 Technical reliability of the alarm system..............3 Alarm system operating costs ..................3 Glossary .......................... 4 Control panel compliance with EN 50131 standard requirements for Grade 2 ..5 Operating the alarm system with LCD keypad............. 6 Keypads description .......................
  • Page 4 VERSA Plus SATEL 6.16.3 Selecting the arming mode ......................28 6.17 Programming the telephone numbers to be notified ............28 6.18 Programming codes to acknowledge / clear messaging............30 6.19 Checking the troubles / system state ................... 30 6.19.1 Information on system state ....................... 30 6.19.2...
  • Page 5: Introduction

    The SATEL Company is manufacturer of a broad range of devices dedicated for use in security alarm systems. Further information is available on our website www.satel.eu or at the points of sale offering our products.
  • Page 6: Glossary

    VERSA Plus SATEL 4. Glossary Alarm – reaction of the alarm system to detection by the detectors of an intruder in the protected area, or to another event within the protected area (e.g. glass pane break, gas detection, etc.). The alarm can be signaled in keypads, proximity card arm/disarm devices, or by sirens (during a defined time or until cleared).
  • Page 7: Control Panel Compliance With En 50131 Standard Requirements For Grade 2

    SATEL VERSA Plus Protected area – the area supervised by detectors being part of the alarm system. Proximity card – a passive transponder that allows the user to operate the alarm system by means of a proximity card reader (INT-CR and INT-IT proximity card arm/disarm devices are provided with the reader).
  • Page 8: Operating The Alarm System With Lcd Keypad

    Fig. 1. VERSA-LCDM keypad (the VERSA-LCDR and VERSA-LCDM-WRL keypads differ only in some graphic elements on its glass). Fig. 2. VERSA-LCD keypad. SATEL offers the following LCD keypads for VERSA Plus control panels: VERSA-LCDM – hardwired keypad, VERSA-LCDR – hardwired keypad with built-in proximity card reader,...
  • Page 9: Keypads Description

    SATEL VERSA Plus VERSA-LCD – hardwired keypad. The keypads are available in a variety of color options for the display and key backlight. The color variant is indicated by the additional designation in the keypad name (e.g. VERSA-LCD-GR – green display and keys backlight; VERSA-LCDM-WH – white display and keys backlight).
  • Page 10: Display

    VERSA Plus SATEL When you are using the user menu or service menu, the LED is:  blinking rapidly during navigation through the menus and submenus,  steady on after a function is started. 6.1.2 Display The display provides a number of data, facilitating communication between the alarm system and the user.
  • Page 11: Keys

    SATEL VERSA Plus If the G 2 global option is enabled by the installer, the messages on alarms and RADE tampers are not displayed. 6.1.3 Keys The keys bearing digits and letters enable entering the code, as well as data when the keypad is being used.
  • Page 12 VERSA Plus SATEL – selecting the partition which is to be armed or disarmed, or where alarm is to be cleared – in such a case the keypad is waiting for the code to be entered, – turning output off, –...
  • Page 13: Codes

    SATEL VERSA Plus Codes Operating the alarm system by means of the keypad is possible after entering the code. Only some functions can be run without the code being entered. Do not make your code available to other people. Using an incorrect code three times may: ...
  • Page 14: Arming The Selected Partition

    VERSA Plus SATEL The reader in VERSA-LCDM-WRL keypad is enabled:  for 5 seconds after disappearance of the connection establishment message (the message is displayed after the keypad is activated by pressing any key),  for 20 seconds after pressing the keys simultaneously.
  • Page 15: Denial Of Arming And Forced Arming

    SATEL VERSA Plus “Bypassed zones 1=Arm” – if you don’t have the Z right. You can: ONE INHIBITION – press the key to cancel the arming, – press the key to proceed with the arming. 6.3.7 Denial of arming and forced arming...
  • Page 16: Disarming And Alarm Clearing

    VERSA Plus SATEL If the arming has been forced, the control panel will ignore violations and troubles which took place after starting the arming procedure. Disarming and alarm clearing Disarming and alarm clearing are carried out in the same way, the procedures being interconnected.
  • Page 17: Triggering The Alarm From Keypad

    SATEL VERSA Plus To terminate the function of partition state presentation, press . The keypad will quit the function automatically after 2 minutes. Triggering the alarm from keypad The installer can permit triggering alarms from the keypad. To trigger an alarm, do the following: fire alarm –...
  • Page 18: Step By Step" Programming Method

    VERSA Plus SATEL 6.8.2 “Step by step” programming method In case of some functions (e.g. adding and editing users, configuring timers, etc.), the programming is effected by using the “step by step” method. After calling the function and selecting the item to be configured from the list, the first parameter available for programming will be displayed.
  • Page 19: User Functions List

    SATEL VERSA Plus Characters available after next keystroke  " & < > Table 2. Characters available when entering names. The upper case letters are available under the same keys (to change the letter case, press Shown on the left side in the upper line of the display is information about the letter case: [Abc], [ABC] or [abc] (it will be displayed after pressing any key and will be visible for a few seconds after the last keystroke).
  • Page 20: Change Own Code

    VERSA Plus SATEL [63#] 3. Timers programming the timers [64#] 4. Tel. numbers programming telephone numbers to be notified [65#] 5. Msg.clr.codes programming codes to acknowledge / clear messaging [7#] 7. System state checking troubles / checking partition, alarm, trouble status [8#] 8.
  • Page 21: Adding A User

    SATEL VERSA Plus 6.10.1 Adding a user 1. Enter the user menu and press in turn . Adding the user is effected by the “step by step” method, hence the programming step number is presented on the LEDs of the first and second partitions (see: page 16, Table 1).
  • Page 22 VERSA Plus SATEL have access. Information on the selected partition(s) will appear in the lower display line. Press to confirm your selection. 5. Step 5. Adding 433 MHz keyfob. If the INT-RX-S, INT-RX or VERSA-MCU module is connected to the control panel, the user may be assigned a 433 MHz keyfob. Press in...
  • Page 23 SATEL VERSA Plus 31. Arming partition 1 – full armed mode 32. Arming partition 1 – night armed mode 33. Arming partition 1 – day armed mode 34. Disarming / clearing alarm in partition 1 35. Arming partition 2 – full armed mode 36.
  • Page 24 VERSA Plus SATEL 98. Output 8 switchover 99. Output 9 switchover 100. Output 10 switchover 101. Output 11 switchover 102. Output 12 switchover Contact the installer to obtain information on the zone types and output functions. 9. Step 5d. Assigning function to 433 MHz keyfob button 2. Proceed in the same way as in Step 5c.
  • Page 25 SATEL VERSA Plus 23. Step 6i. Selecting confirmation for LED 1 in APT-100 keyfob. Press to confirm the default method of confirmation (defined by the installer in the user schedule) or enter the number of one of the following functions and then press 0.
  • Page 26: User Editing

    VERSA Plus SATEL 28. Step 7b. Adding proximity card. Depending on the selected method: – enter the card code (see: “Entering hexadecimal characters” p. 16) and press – bring the card twice close to the reader (displayed messages will prompt you what to do).
  • Page 27: Removing A User

    SATEL VERSA Plus – in turn, if the user has a keyfob and you want to edit functions assigned to the keyfob buttons (the procedure is similar to that for assigning functions after an APT-100 keyfob has been added to a new user), –...
  • Page 28: Zone Inhibiting

    VERSA Plus SATEL The zone bypassing functions can also be used to unbypass the zones (the zone inhibiting function makes it also possible to unbypass an isolated zone, while the zone isolating function makes it also possible to unbypass an inhibited zone).
  • Page 29: Auto-Arming Deferment

    SATEL VERSA Plus 6.14 Auto-arming deferment Partition can be armed automatically by the timer on specific days at specific time. If the installer defines the time by which the auto-arming is to be deferred, you can defer the arming. 6.14.1 Simple auto-arming deferment...
  • Page 30: Programming The Weekly Schedule

    VERSA Plus SATEL Irrespective of the selected parameter, pressing the key in a subsequent step will take you back to Step 2. 6.16.1 Programming the weekly schedule 1. Step 3. Programming timer activation/deactivation time on Monday. Use the keys to move the cursor. If you want, you can only program the activation or deactivation time.
  • Page 31 SATEL VERSA Plus - telephone 2, - telephone 3, - telephone 4, - telephone 5, - telephone 6, - telephone 7, - telephone 8. 3. Enter the telephone number (the available characters are presented in Table 4). You can enter p to 16 characters.
  • Page 32: Programming Codes To Acknowledge / Clear Messaging

    VERSA Plus SATEL 6.18 Programming codes to acknowledge / clear messaging 1. Enter th user menu and press in turn 2. Press in turn the suitable keys to select the telephone number for whic h the code to acknowledge / clear voice messaging is to be defined (the phone numbers to which voice...
  • Page 33: Output Control

    SATEL VERSA Plus If the S option is enabled in the control panel, ERVICE MESSAGE AFTER TAMPER ALARM only the installer can clear the tamper alarm memory. 6.20 Output control Using the keypad, you can control the operation of devices connected to the outputs (e.g. to raise wer roller blinds/shutters, turn on/off lighting or heating, etc.).
  • Page 34: Output Test

    VERSA Plus SATEL When testing the zones, the keypad does not present the current zone state, but only indicates whether or not the zone was violated during the test. 1. Enter the user menu and press in turn 2. En ter two digits to define the test duration (e.g.
  • Page 35: Checking The Firmware Version Of Control Panel

    (IP address, MAC address, individual identification number for the purpose of commun ication via the SATEL server [ID], individual identification number of the GSM pho e [IM I]). 6.21.8 Checking the current supply voltage in modules all m odules provide information on the current voltage.
  • Page 36: Defining The Service Access Time

    VERSA Plus SATEL Permanent access – if the option is enabled, the service code can be used to get access to the alarm system at all times. If the alarm system is to meet requirements of th e EN 50131 standard for Grade 2, the service code access should be time limited.
  • Page 37 SATEL VERSA Plus Fig. 3. APT-100 keyfob (gray enclosure). A – numeration of LEDs. B – numeration of keyfob buttons (button 6 – pressing buttons 1 and 5 simultaneously). Fig. 4. T-4 keyfob [433 MHz keyfob]. A – numeration of keyfob buttons (button 5 – pressing buttons 1 and 2 simultaneously;...
  • Page 38: Denial Of Arming

    VERSA Plus SATEL Denial of arming The information given below is not applicable, if the keyfob button controls arming zone. The installer can program the control panel so that arming by means of keyfob is not possible when:  in the partition to be armed, at least one zone that must not be violated during arming (the...
  • Page 39: Starting The Operating By Telephone

    SATEL VERSA Plus The installer can make the option of operating the system by phone conditional on the partition state (the operation being only possible when the selected partitions are armed). Starting the operating by telephone The control panel can have three phone numbers: analog communicator number, SIM1 card number and SIM2 card number.
  • Page 40 VERSA Plus SATEL 1 – arm in full mode 2 – arm in night mode 3 – arm in day mode 6 – disarm 7 – arm despite obstacles 9 – clear alarms 0 – another partition # – next partition * –...
  • Page 41: Ending The Operating By Telephone

    SATEL VERSA Plus * – main menu Ending the operating by telephone 1. Press * key. 2. Press in turn the 0# keys. The control panel will go on-hook. The control panel will goes on hook automatically after one minute of idle state.
  • Page 42  enter the name of control panel (to enable identification of the control panel when using the application),  enter the MAC address of control panel (the hardware address of built-in Ethernet communication module),  enter the ID number of control panel (the individual identification number for the purpose of communication via the SATEL server),...
  • Page 43: Manual Update History

    SATEL VERSA Plus  enter the user code (which will be used when operating the control panel by means of the application),  select an icon for the control panel (to facilitate identification of the control panel when using the application), ...
