Pioneer Eclipse Mean Machine Operator's Manual page 18

Deck Sub-Assembly: Machines with Steel Skirt
REF# PART# DESCRIPTION
301 MP8070 Belt, BX-46 (21" models)
MP8150 Belt, BX-49 (24" models)
MP041000 Belt, BX-56 (28" models)
302 NB001900 Washer, Fender, 1/2
303 NB6863 Screw, Hex HD, 1/2 x 1
304 NB3450 Washer, Flat, 3/8
305 NB6044 Screw, Cap, 3/8 x 1 1/4
306 MP9610 Meter, Hour
307 NB2643 Rivet, Pop 1/8 x 1/4
308 NB5282 Screw, BH, 5/16 - 18 x 1
309 MP120600 Pad, Tank
310 NB003100 Nut, Hex, 1/2" - 13, JAM
311 MP035300 Band, Clamp, Skirt
312 NB020700 Screw, Phillips, Pan 6 - 32 x 1
313 MP084700 Molding, Bumper, RokBak
314 NB020800 Nut, Lock, Nylon, 6 - 32
315 MP012801 Caster, 2 1/2", Rear
316 MP068300 Bracket, Wheel (21" models)
MP069000 Bracket, Wheel (24" & 28" models)
317 MP105300 Wheel, 5", Performa
318 MP038100 Pin, Clevis, 3/8 x 2 1/8
319 NB3265 Nut, Lock, 5/16
320 LX2105 Clip, Hitch, Pin
321 MP071800 Tensioner, Belt, w/4" Pulley
322 MP107700 Spindle, w/6.75" Pulley (21" models)
MP7235 Spindle, w/7.25" Pulley (24" models)
MP7240 Spindle, w/8.75" Pulley (28" models)
324 MP081300 Ring, Relief, Stress, Padholder
325 NB3275 Nut, Lock, 1/4
326 MP8275D Padholder, 21"
MP048300 Padholder, 24"
SA004000 Padholder, 28"
327 NB5700 Washer, 0.755 x 1.005 x 0.060, SS
328 MP195800 Flexi-Disc, w/o Lip, Yellow, 80 Duro.
329 MP066300 Ring, Spacer, Center Loc II
(24" & 28" models)
330 MP012700 Retainer, Pad, Center Loc II
(24" & 28" models)
MP8505 Pad Grab III (21" models)
QTY REF# PART#
1 331 NB3350
1
332 NB9319
1
333 PD006021
4
PD006024
4 PD006028
5 334 MP095200
MP047500
1
MP032500
1
335 MP8310
3
4
1
336 SA003900
1
SA007800
2
SA004000
4
337 MP031802
1
MP031800
4
MP031801
1
338 MP139200
2
MP139300
2
MP139400
2
339 NB008900
2
6
2 340 NB044000
1 341 NB043900
1 342 MP140000
1
343 MP139800
1
1
6 344 MP139700
1
1
1 345 NB050600
1 346 NB3350
1 347 MX1045
348 NB6501
1
349 MP247300
1 MP247400
1 MP246600
350 MP196300
DESCRIPTION
Washer, Flat, 1/4
Screw, BH, 1/4 - 20 x 1 1/4
Pad, 21" Blue Blend
Pad, 24", Blue Blend
Pad, 28", Blue Blend
Padholder, 21", Complete Asm.
Padholder, 24", Complete Asm.
Padholder, 28", Complete Asm.
Velcro, Hook, Studs (21" models)
(24" models)
(28" models)
Padholder, w/studs, 21"
Padholder, w/studs, 24"
Padholder, w/studs, 28"
Bumper, Shroud, Low Prof., 21"
Bumper, Shroud, Low Prof., 24"
Bumper, Shroud, Low Prof., 28"
Skirt, Steel, 21", Asm.
Skirt, Steel, 24", Asm.
Skirt, Steel, 28", Asm.
Rivet, Pop, 3/16", 3/18 HD (21")
(24")
(28")
Washer, Flat, #10, Black
Rivet, 3/16 x 1/2 x 5/8 HD, Black
Felt, Dot
Edging, Wear, Skirt, Steel (21") 6.03 ft.
Edging, Wear, Skirt, Steel (24") 7.10 ft.
Edging, Wear, Skirt, Steel (28") 8.14 ft.
Molding, Bumper, Skirt, Steel (21")4.08 ft.
Molding, Bumper, Skirt, Steel (24")5.02 ft.
Molding, Bumper, Skirt, Steel (28")6.07 ft.
Bolt, Hex, Tap, 1/4-20 x 2 1/2"
Washer, Flat, 1/4
Nut, Hex, 1/4-20
Insert, 1/4-20, .027-.165 Grip,
Comp. Typ
Skirt, Steel, 21", Tab., Painted
Skirt, Steel, 24", Tab., Painted
Skirt, Steel, 28", Tab., Painted
Ring, Relief, Stress, Large, Padholder 1
QTY
6
6
1
1
1
1
1
1
50
76
68
1
1
1
1
1
1
1
1
1
10
10
12
4
4
2
1
2
1
1
1
1
1
