Pioneer Eclipse Mean Machine Operator's Manual page 16

Deck Sub-Assembly: Kawasaki Mean Machine
REF PART# DESCRIPTION
301 MP107600 Belt, BX-47 (21" models w/out clutch)
MP8070 Belt, BX-46 (21" models w/clutch)
MP8150 Belt, BX-49 (24" models)
MP041000 Belt, BX-56 (28" models)
302 NB001900 Washer, Fender, 1/2
303 NB6863 Screw, Hex HD, 1/2 x 1
304 NB3450 Washer, Flat, 3/8
305 NB6044 Screw, Cap, 3/8 x 1 1/4
306 MP9610 Meter, Hour
307 NB2643 Rivet, Pop 1/8 x 1/4
308 NB5282 Screw, BH, 5/16 - 18 x 1
310 NB003100 Nut, Hex, 1/2" - 13, JAM
311 MP035300 Band, Clamp, Skirt
312 NB020700 Screw, Phillips, Pan 6 - 32 x 1
313 MP084700 Molding, Bumper, RokBak
314 NB020800 Nut, Lock, Nylon, 6 - 32
315 MP012801 Caster, 2 1/2", Rear
316 MP068300 Bracket, Wheel (21" models)
MP069000 Bracket, Wheel (24" & 28" models)
317 MP105300 Wheel, 5", Performa
318 MP038100 Pin, Clevis, 3/8 x 2 1/8
319 NB3265 Nut, Lock, 5/16
320 LX2105 Clip, Hitch, Pin
321 MP071800 Tensioner, Belt, w/4" Pulley
322 MP107700 Spindle, w/6.75" Pulley (21" models)
MP7235 Spindle, w/7.25" Pulley (24" models)
MP7240 Spindle, w/8.75" Pulley (28" models)
324 MP081300 Ring, Relief, Stress, Padholder
325 NB3275 Nut, Lock, 1/4
326 MP8275D Padholder, 21"
MP048300 Padholder, 24"
SA004000 Padholder, 28"
327 NB5700 Washer, 0.755 x 1.005 x 0.060, SS
328 MP195800 Flexi Disc, w/out Lip, yellow, 80 duro
329 MP066300 Ring, Spacer, Center Loc II
(24" & 28" models)
330 MP012700 Retainer, Pad, Center Loc II
(24" & 28" models)
MP8505 Pad Grab III (21" models)
331 NB3350 Washer, Flat, 1/4
332 NB9319 Screw, BH, 1/4 - 20 x 1 1/4
333 PD006021 Pad, 21" Blue Blend
PD006024 Pad, 24", Blue Blend
PD006028 Pad, 28", Blue Blend
334 MP095200 Padholder, 21", Complete Asm.
MP047500 Padholder, 24", Complete Asm.
MP032500 Padholder, 28", Complete Asm.
335 MP8310 Velcro, Hook, Studs
(21" models)
(24" models)
(28" models)
336 SA003900 Padholder, w/studs, 21"
SA007800 Padholder, w/studs, 24"
SA004000 Padholder, w/studs, 28"
QTY
1
1
1
1
4
4
5
1
1
3
4
1
2
4
1
4
1
2
2
2
2
6
2
1
1
1
1
1
6
1
1
1
1
1
1
1
1
6
6
1
1
1
1
1
1
50
76
68
1
1
1
