Pioneer Eclipse Mean Machine Operator's Manual page 14

Engine Sub-Assembly: Kawasaki Mean Machine
REF PART# DESCRIPTION
400 MP109600 Filter, Recoil (13 HP)
MP109700 Filter, Recoil (17 HP)
401 MP109200 Engine, Kawasaki, 13 HP, 12 V
MP102900 Engine, Kawasaki, 13 HP, 110 V
MP03000 Engine, Kawasaki, 17 HP, 12 V
MP093200 Engine, Kawasaki, 17 Hp, 110 V
402 NB1621 Caplug, K8, Red
403 MP4515 Tubing, Oil Drain
404 MP072300 Valve, Oil Drain, Kawasaki
405 KA590717004 Oil Drain Adapter
406 MP109500 Seal, Foam (13 HP)
MP043100 Engine Air Intake Seal (17 HP)
407 SA007900 Plate, Throttle, Repl., Bail Style Kit
408 KA110137016 Element, Air Filter - Foam (13 HP)
KA110137001 Element, Air Filter - Foam (17 HP)
409 NB000100 Screw, HH, 5/16 - 18 x 1 3/4"
410 MP019200 Oil Pressure Switch
411 KA490652078 Oil Filter
412 KA110137017 Element, Air Filter - Main (13 HP)
KA110137002 Element, Air Filter - Main (17 HP)
413 MP121900 Shield, Manifold (13 HP)
MP043400 Shield, Manifold (17 HP)
414 KA110607006 Gasket - Exhaust
415 MP036200 Switch, Micro, 12 V, 15 A
416 MP4800 Spacer, Clutch, Top (models w/clutch)
417 MP107400 Muffler, Catalytic (13 HP)
MP107300 Muffler, Catalytic (17 HP)
418 MP015200 Plug, Oxygen Sensor
MP018000 Oxygen Sensor (models w/EcoSense)
419 MP023500 Pulley, 4", AB Sheave (models w/out clutch) 1
420 MP4787 Clutch Assy. (models w/clutch)
421 MP4805 Spacer, Clutch Bottom (models w/clutch)
422 NB005800 Screw, HH, 7/16 - 20 x 1 1/2
423 NB9267 Washer, Flat, 5/16
424 MP4790 Tubing (models w/clutch)
425 NB52816 Screw, BH, 1/4 - 20 x 1/2"
426 NB3265 Nut, Lock, 5/16 - 18
427 NB9545 Nut, Spin Lock, 1/4 - 20
428 NB5282 Bolt, BH, 5/16 - 18 x 1
429 MP120500 Bracket, Muffler
430 KA920707003 Plug, Spark, (RCJ8Y) (Not Shown)
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
4
1
1
3
1
2
1
2
032207
13
