When battery replacement becomes
necessary, the replacement should have the
same specifications as the original. If in
doubt, contact Amano Pioneer Eclipse
Customer Service at 1-800-367-3550 or
1-336-372-8080. To replace:
1. Remove the propane fuel cylinder from
the machine.
2. Disconnect battery cables from terminals.
Always disconnect the BLACK cable first.
3. Remove battery hold-down clamp.
4. Lift old battery out and replace with new
battery.
5. Reinstall hold-down clamp.
6. Connect the RED positive battery cable
first.
Connect the BLACK negative battery
cable last.
Dispose of old battery in the proper manner.
Most auto parts stores accept used batteries
for recycling.
Belt Maintenance
To inspect the belt it is necessary to turn the
machine over. The machine should be
rocked back to the vertical position. If the belt
is badly cracked or worn it should be
replaced.

PROPOSITION 65 WARNING

Battery posts, terminals, and related
accessories contain lead and lead
compounds, chemicals known to the
State of California to cause cancer
and reproductive harm.
Batteries also contain other chemicals
known to the State of California to
cause cancer.
Wash hands after handling.
To check for the proper tightness squeeze
the belt together. The belt should depress
between 1/4" (0,6 cm) and 1/2" (1,3 cm).
Always use the recommended belt size.
To change belt:
1. Remove the pad holder by holding the
end of the shaft on the top of the machine
with a 3/4" wrench and turn the pad
holder counterclockwise.
2. Use the 3/4" wrench to turn the end of the
spindle shaft on top of the machine while
removing the old belt from the spindle
pulley.
3. Finish removing the belt from the engine
pulley, if necessary.
4. Check engine pulley for correct alignment
with the spindle pulley. Check hardware
attaching pulleys for proper tightness.
5. Install the new belt onto the engine pulley.
6. Reinstall the new belt onto the spindle
pulley using the 3/4" wrench to turn the
spindle clockwise. Make sure the belt is
correctly placed on the idler pulley.
7. Reinstall the pad holder onto the spindle
shaft.
8. Turn the machine upright in the
burnishing position.
9. Check belt for correct operation. Check
all hardware for proper tightness.
Adjusting the Handle and RokBak
1. With the engine OFF, loosen the handle
adjustment lever on the side of the
handle.
2. Move the handle to the full-up position
(about a 45° angle) and retighten handle
adjustment lever securely.
3. Lift up on the front of the deck, rocking
the machine back until it rests on the
handle grips.
Adjusting the Wheel Brackets
The burnisher is equipped with wheel
brackets that allow the wheels to be moved
forward or backward. To reduce weight on
the pad, the wheels can be moved forward or
to add weight, moved to the rear.
This feature aids the operator in adjusting the
machine for different types of floor finish. It
can also help in balancing the machine if a
steel tank is used in place of an aluminum
cylinder.
NOTE: Aluminum cylinders with safety
devices for overfill prevention are
recommended.

Troubleshooting

Symptom: Hard to start
Possible Causes:
Opening propane cylinder too quickly (OPEN
SLOWLY)
Low oil
Insufficient vacuum
Coil, air gap needs adjusting
Spark plug or head bolts loose
Blown head gasket
Symptom: Will not start
Possible Causes:
No fuel
Low oil
Wires broken or disconnected
Incorrect spark plug gap (Gap should be .025)
Insufficient vacuum
Defective spark plug
Defective coil
Blown head gasket
Symptom: Engine lacks power
Possible Causes:
Insufficient vacuum
Dirty air filters
Governor needs adjusting
Leaking head gasket
No compression - worn rings
Symptom: Smell of burned rubber
Possible Cause:
Belt out of adjustment - check
automatic tensioner
Symptom: Machine vibrates
Possible Causes:
Loose nuts
Pad not centered
Symptom: Machine "Bogs Down" when in
use
Possible Causes:
Operator bearing down too hard
Dirty air filters
Symptom: Machine pulls to one side
Possible Causes:
Bent wheel bracket or worn wheel
Adjust wheels forward
Symptom: Engine stops running
Possible Causes:
Out of fuel
Low oil
Dirty air filter
