Accessories

DAP over CAN Physical Layer Converter is used together with the following iSYSTEM
hardware:
Ordering Code
IC57000
IC57163
IC57164
IASAM22TRICOREPIN
10
BB-FNET-100
BB-FNET-300
BB-FNET-500
BB-FNETMICRO-100
Please refer to the iC5700 BlueBox for all current iC5700 Accessories.
The functionality of the DAP over CAN Physical Layer Converter can be extended through the
use of various accessories.
Ordering Code
IC57040-CAN-DB9
IC57040-CAN-PIN
IC57040-CAN-JACK
IC57040-CAN-T
Find more information on
for technical support please visit www.isystem.com/support.
Description
iC5700 BlueBox
Infineon DAP/DAPE Active Probe
Infineon AGBT Active Probe
10-pin 1.27 mm DAP Adapter (Infineon AGBT Active Probe)
1.0m FNet Cable (Active Probe)
2.0m FNet Cable (Active Probe)
5.0m FNet Cable (Active Probe)
1.0m FNet Micro Cable (Active Probe)
Description
1m CAN cable DB9 plug
CAN cable pin wires
CAN cable banana jacks
CAN BUS T adapter
www.isystem.com or contact sales@isystem.com. To reach
