DAP over CAN

DAP over CAN Physical Layer Converter
ECU connector without opening its housing. This connection is electrically robust due to the
nature of the CAN bus. The DXCPL Converter translates Infineon AURIX™ SPD (Single Pin DAP)
encoded DAP messages to the CAN bus physical layer. iSYSTEM hardware solution supports
DXCPL on Infineon AURIX™ TC2xx and TC3xx devices.
For details about DXCPL operation, refer to
DAP over CAN Physical Layer Converter can be used with:
·
iC5700 BlueBox via DTM or
·
iC5700 BlueBox via
·
iC5700 BlueBox via
Schematic designer must assure the correct state of TRST signal on cold PORST.
iC5700 BlueBox - Hardware platform designed for debugging and testing a wide range of
embedded microcontroller platforms that are based on a variety of processor architectures.
Infineon DAP/DAPE Active Probe
AURIX™ microcontroller family. It supports the DAP and DAPE debug interface operating at
their maximum frequency. Its small and compact hardware size allows for connecting to a
target microcontroller in a confined space as far as 5m away.
Infineon AGBT Active Probe
microcontroller family. It supports the DAP and Aurora GigaBit Trace (AGBT) interface
operating at their maximum frequency. Its small and compact hardware size allows for
connecting to a target microcontroller in a confined space as far as 5m away. The Active
Probe supports up to 4 parallel AGBT lanes, running at a maximum bitrate of 5Gbps.
winIDEA IDE - Integrated Software Development Environment delivers the visual insights
required to debug the embedded application, performs timing analysis, measures code
coverage, visualizes
isystem.com/winideaide.
testIDEA - The testIDEA environment simplifies the development of unit tests for embedded
applications. More information isystem.com/testidea.
isystem.connect - Application programming interface (API) with Software Development Kit
(SDK) and supporting a variety of programming languages makes almost the entire range of
features provided by our software, such as winIDEA, its Analyzer and testIDEA, and the
capabilities of our hardware development tools, such as our BlueBox technology and their IOM
accessories. More information isystem.com/sdk.
- Enables debugging via the regular CAN pins of the
Infineon DAP/DAPE Active Probe
Infineon AGBT Active Probe
- Enables debugging, tracing and testing of Infineon's
- Enables debugging, tracing and testing of Infineon's AURIX™
RTOS task states
Infineon Application Note
or
and a 10-pin 1.27 mm DAP Converter
and much more.
AP32264.
More information
