Installation and Operation
3.3 Cable glands
All cables and wires are inserted into the protective housing via metric cable glands. The size, material and clamping
range of the cable glands can be found in the table below.
Material
Size
Clamping range, mm
Width across flats, mm
16
Cable glands
Brass - nickel-plated
M 12
3 ... 7
16
* Cable gland with 8 sealing inserts for cable diameter 5.3 mm
M 20
7 ... 13
24
M 32
5*
36
Edition: 03.2019
