Sensor 1 to 20 (analog IN)
Number / Ter-
minal
Sensor 1
49
AI1+ (Signal Plus)
50
AI1- (Minus)
51
AI1S (Screen)
Sensor 2
52
AI2+ (Signal Plus)
53
AI2- (Minus)
54
AI2S (Screen)
Sensor 3
55
AI3+ (Signal Plus)
56
AI3- (Minus)
57
AI3S (Screen)
Sensor 4
58
AI4+ (Signal Plus)
59
AI4- (Minus)
60
AI4S (Screen)
Sensor 5
61
AI5+ (Signal Plus)
62
AI5- (Minus)
63
AI5S (Screen)
Sensor 6
64
AI6+ (Signal Plus)
65
AI6- (Minus)
66
AI6S (Screen)
Sensor 7
67
AI7+ (Signal Plus)
68
AI7- (Minus)
69
AI7S (Screen)
Sensor 8
70
AI8+ (Signal Plus)
71
AI8- (Minus)
72
AI8S (Screen)
VIBGUARD IIoT
Designation
Installation and Operation
Sensor 1 to 20 (analog IN)
Number / Ter-
minal
Sensor 9
73
AI9+ (Signal Plus)
74
AI9- (Minus)
75
AI9S (Screen)
Sensor 10
76
AI10+ (Signal Plus)
77
AI10- (Minus)
78
AI10S (Screen)
Sensor 11
79
AI11+ (Signal Plus)
80
AI11- (Minus)
81
AI11S (Screen)
Sensor 12
82
AI12+ (Signal Plus)
83
AI12- (Minus)
84
AI12S (Screen)
Sensor
85
AI13+ (Signal Plus)
13*
86
AI13- (Minus)
87
AI13S (Screen)
Sensor
88
AI14+ (Signal Plus)
14*
89
AI14- (Minus)
90
AI14S (Screen)
Sensor
91
AI15+ (Signal Plus)
15*
92
AI15- (Minus)
93
AI15S (Screen)
Sensor
94
AI16+ (Signal Plus)
16*
95
AI16- (Minus)
96
AI16S (Screen)
Designation
41
