Hard drive

Description
Hard drive
● 1 TB 5400 RPM SATA RAW HYBRID 8 GB
● 2 TB 5400 RPM SATA RAW 9.5 mm
● 1 TB 7200 RPM SATA RAW 9.5 mm
Hard drive connector and cable
Hard drive brackets with rubber
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Service door (see
b. Base enclosure (see
c. Disconnect the battery (see
Remove the hard drive:
NOTE: Use minimal force when lifting the locking bar up on the ZIF connector and disconnecting the cable.
1. Open the zero insertion force (ZIF) connector (1) to release the hard drive cable from the system board.
Service door on page 29)
Base enclosure on page
Battery on page
33)
35)
Component replacement procedures
Spare part number
731999-005
801808-005
766644-005
862964-001
911227-001
37
