TouchPad board

Description
TouchPad board
TouchPad cable
TouchPad rubber click button
Before removing the TouchPad board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Service door (see
b. Base enclosure (see
c. Battery (see
d. Hard drive (see
e. SSD (see
f. Front speakers (see
g. Fans (see
h. Heatsink (see
i. System board (see
Remove the TouchPad board:
1. Carefully remove the three Phillips M2x2.5 screws (1) that secure the TouchPad bracket to the computer.
2. Remove the TouchPad bracket (2) that secures the TouchPad board.
3. If it is necessary to replace the TouchPad rubber click button, lift the rubber button (3) away from the
TouchPad.
Service door on page
Base enclosure on page
Battery on page 35)
Hard drive on page
SSD (M.2) on page 39)
Front speakers on page
Fans on page 44)
Heatsink on page 45)
System board on page
29)
33)
37)
40)
47)
Spare part number
862959-001
862966-001
910443-001
Component replacement procedures 59
