Summary of Contents for M-system JC-IO
- Page 1 I/O CONNECTION MODULE Model: JC-IO USERS MANUAL 5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN Tel: +81-6-6659-8201 Fax: +81-6-6659-8510 https://www.m-system.co.jp/ E-mail: info@m-system.co.jp JC-IO USERS MANUAL EM-9044-B...
-
Page 2: Table Of Contents
4.3.2 Network Setting ............................18 4.4 Setting Value ............................ 19 4.4.1 Starting screen ............................19 4.4.2 Communication (HTTP/SNTP).........................20 4.4.3 C (Connection) ............................21 4.4.4 Communication Error Output ........................22 4.4.5 L (32-bit) ..............................23 4.4.6 S (16-bit) ..............................25 4.4.7 B (1-bit) ..............................26 JC-IO USERS MANUAL EM-9044-B... - Page 3 6.1 I/O Transmission (IP telemeter) .......................37 6.2 I/O Extension of PLC ........................37 7. TROUBLE SHOOTING 7.1 JCIOCFG ............................38 7.2 LED Indication ..........................38 7.3 LAN Connection ..........................39 7.4 Modbus (client) ..........................39 7.5 SLMP (client) ...........................40 8. LICENSE JC-IO USERS MANUAL EM-9044-B...
-
Page 4: Introduction
Confirm Model No. marking on the product to be exactly what you ordered. 1.2 Corresponding Versions ■ UNIT VERSION This Users Manual corresponds to model JC-IO firmware version 1.0.x. Refer to the 4.5.2 Information (Version, MAC address) to confirm the unit version. This Users Manual corresponds to PC configurator software version 1.0.x. -
Page 5: Precautions
The battery is charged when the power is supplied. • The battery is not replaceable by customer. When replacement is required, consult M-System. ■ AND .. -
Page 6: Terms
Web server A web server that connected from browser software of the PC to JC-IO-N by HTTP and enables monitoring the data and conducting maintenance. Unlike a general-purpose web server, CGI and others are not operable. -
Page 7: Specifications
POWER, RUN, COM, ERROR RUN contact output Photo MOSFET relay (no polarity); (OFF in CPU error detected) •Peak load voltage: 50 V max. •Continuous load current: 50 mA max. •Peak load current: 300 mA max. (≤0.1 sec.) JC-IO USERS MANUAL EM-9044-B... - Page 8 No corrosive gas or heavy dust Mounting DIN rail Weight 190 g (0.42 lb) Table 7. Calender Clock ITEM DESCRIPTION Calendar clock accuracy Monthly deviation 2 minutes at 25°C Battery backup Approx. 2 months Battery Vanadium-lithium secondary battery (undetachable) JC-IO USERS MANUAL EM-9044-B...
-
Page 9: Component Identification
Blinking at remote I/O communication error Blinking at communication Green (except Modbus/TCP & SLMP) ERROR ON at CPU error ■ Ethernet INDICATOR LED COLOR FUNCTION DPLX Green ON with full-duplex communication Yellow ON at LINK is established JC-IO USERS MANUAL EM-9044-B... -
Page 10: System Configuration
2. SYSTEM CONFIGURATION 2.1 Basic Configuration JC-IO-N saves the read data from remote I/O for input signal to the internal register, and transmit the data to the remote I/ O for output. This is called as I/O mapping. JC-IO-N Modbus/TCP... -
Page 11: Variable Type
2.3 Variable Type JC-IO-N can handle the following valiable types Table 9. Variable Type VARIABLE INTERNAL RANGE REMARKS TYPE REGISTER 0, 1 0 or 1 SHORT -32,768 to 32,767 Signed 16-bit integer USHORT 0 to 65,535 16-bit integer LONG -2,147,483,648 to 2,147,483,647... -
Page 12: I/O Communication
Connecting Device Set the IP address, and port number. 3.2 Output Conditions The JC-IO-N updates the internal register when acquiring the input data from input connection or "manual operation". After the first update of the internal register, output connection starts outputting. -
Page 13: Modbus/Tcp
3.4 Modbus/TCP The JC-IO-N supports Modbus/TCP as I/O communication, so communicable with Modbus/TCP supported remote I/O and PLCs is possible. Table 12. Modbus/TCP ITEM DESCRIPTION TYPE OPERATION Read Coil Status (01) Reading out Coil Status(0X) Read Input Status (02) Reading out Input Status(1X) -
Page 14: Slmp
3.5 SLMP The JC-IO-N supports SLMP as I/O communication, so communicable with Mitsubishi programmable-control- ler. Compatible to sub-command of 16-bit and 32-bit. MELSEC iQ-R, Q, and iQ-F are operation tested. Refer to the following table for compatible MELSEC devices for internal register. -
Page 15: Input (L, P)
1402H 0000H 1402H 0002H × × ✓ 002CH 1402H 0000H × × × 1402H 0002H × × *When using L and P, enable SWAP, as the small address is upper and the large address is lower. JC-IO USERS MANUAL EM-9044-B... -
Page 16: Output (B, Abnormal Communication Output)
× ✓ ✓ 0055H 1402H 0001H × × 1402H 0003H × × ✓ LSTC 0058H 1402H 0001H × × × 1402H 0003H × × ✓ LSTS 0059H 1402H 0001H × × × 1402H 0003H × × JC-IO USERS MANUAL EM-9044-B... -
Page 17: Jciocfg
Web server can also configurate same parameters as JCIOCFG without COP-US. Refer to 5. WEB SERVER for details of web server. 4.2 Version The software version of the JC-IO can be checked as following. 1. Click 2. Click JC-IO USERS MANUAL EM-9044-B... -
Page 18: Basic Settings
COM Port Setting 4.3.2 Network Setting After setting the COM port, JCIOCFG is ready to communicate with the JC-IO. Turn on the JC-IO-N and connect to the Windows PC via COP-US, then set the network as following. 2. Set 3. Click 1. -
Page 19: Setting Value
Table 19. Main Screen of Setting ITEM DESCRIPTION New setting Create new configurations. All setting Values are initial value. Download from device Download the configurations from the JC-IO-N. Read file Read out the configurations saved in the file. JC-IO USERS MANUAL EM-9044-B... -
Page 20: Communication (Http/Sntp)
In the Time Zone field, set to +09:00 in case of using in Japan. Setting the start time of the time correction. When connecting multiple JC-IO-N units to one router, set this time a few minutes apart. Change the COM port number. -
Page 21: C (Connection)
Set the station No. of the programable controller. Processor No. Set the processor no. of the programmable controller in the hexa- decimal number from 0x0000 to 0xFFFF. Type Select the sub-command type of SLMP from 16-bits or 32-bits. Refer to 3.5 SLMP JC-IO USERS MANUAL EM-9044-B... -
Page 22: Communication Error Output
4.4.4 Communication Error Output JC-IO-N can set communication error output for each Connection. Refer to 3.3 Communication Error Output ITEM DESCRIPTION Mode Enable / Disable the communication error output. Following parameters are configurable when Enable is selected. Connection Set the Connetion to output communication error. -
Page 23: L (32-Bit)
Select Enable / Disable. Modubus/TCP Eneble: small address is lower, large address is upper Disable: small address is upper, large address is lower SLMP Differs between PLC and device. Set in necessary. Refer to 3.5 SLMP JC-IO USERS MANUAL EM-9044-B... - Page 24 Select Enable / Disable. Modubus/TCP Eneble: small address is lower, large address is upper Disable: small address is upper, large address is lower SLMP Differs between PLC and device. Set in necessary. Refer to 3.5 SLMP JC-IO USERS MANUAL EM-9044-B...
-
Page 25: S (16-Bit)
SLMP When the protocol of the specified Connection is set to SLMP, set the output device. The display format for device address can be switched between octal, decimal, and hexadecimal. JC-IO USERS MANUAL EM-9044-B... -
Page 26: B (1-Bit)
When the protocol of the specified Connection is set to SLMP, set the output device. The display format for device address can be switched between octal, decimal, and hexadecimal. Invert Invert the output when Enable is selected. JC-IO USERS MANUAL EM-9044-B... -
Page 27: P (32-Bit, Pulse Transmission)
Differs between PLC and device. Set in necessary. Refer to 3.5 SLMP Pulse range JC-IO accumulates the difference of pulse counter between sampling. Set the same value as the pulse range set in the remote I/O. Setting range is as following. -
Page 28: Maintenance
Select “Maintenance” 2. Select 1. Click 3. Click Figure 14. Data/Time Setting VIew 4.5.2 Information (Version, MAC address) Firmware version of the JC-IO-N and the Ethernet MAC address can be checked. 1. Click Figure 15. Information JC-IO USERS MANUAL EM-9044-B... -
Page 29: System Log
Ethernet LINK is in abnormal operation When a problem occurs, M-system's service staff may check the contents of the system log for analysis. Because many of the messages in the system log are unique to M-system, such as internal processing, the details of each log are not described. -
Page 30: Web Server
If not, reconfirm the network connection and the setting. Figure 17. Index Screen Be sure to change the login and password from the default setting. The web server function can only be used under a LAN environment. DO NOT access via the Internet. JC-IO USERS MANUAL EM-9044-B... -
Page 31: Monitoring
Click [Control End] button to finish manual operation and returns to I/O communicating status. Click Click Figure 20. Monitoring Screen (L) Manual Operation The manual operation status is not retained in the power failure. Refer to 2.2 Internal Register or the relationship with SWAP. JC-IO USERS MANUAL EM-9044-B... -
Page 32: Monitoring Screen (S)
The background of the channel under manual operation turns to yellow, as shown in the figure below. Click [Control End] button to finish manual operation and returns to I/O communicating status. Click Click Figure 22. Monitoring Screen (S) Manual Operation The manual operation status is not retained when the power failure. JC-IO USERS MANUAL EM-9044-B... -
Page 33: Monitoring Screen (B)
Click [Control End] button to finish manual operation and returns to I/O communicating status. Click Click Figure 24. Monitoring Screen (B) Manual Operation The manual operation status is not retained when the power failure. When the output is set to "Invert", set the value before invert. JC-IO USERS MANUAL EM-9044-B... -
Page 34: Monitoring Screen (P)
Clicking the "P" button while monitoring the list of P registers the automatic update cycle can be set from 1 to 999 seconds. Figure 25. Monitoring Screen (P) Refer to 2.2 Internal Register or the relationship with SWAP. JC-IO USERS MANUAL EM-9044-B... -
Page 35: Settings
Network New setting The Network setting screen is shown with the default values. Download The Network setting screen is shown with the values downloaded from the JC-IO-N. Language Switch Japanese / English. The setting is not saved. 5.3.2 Setting Screen The functions of setting screen is common with JCIOCFG. -
Page 36: Network Setting Screen
5.3.3 Network Setting Screen The functions of network setting screen is common with JCIOCFG. Refer to 4.3.2 Network Setting for details of setting screen. Click [Upload] to upload to the JC-IO-N. Click Figure 28. Network Setting Screen 5.4 Maintenance The functions of maintenance screen is common with JCIOCFG. -
Page 37: Usage Examples
6.1 I/O Transmission (IP telemeter) Connect remote I/Os in remote locations via the internet and use JC-IO-N as an IP telemeter. In the following figure, capture the alarm signal in the factory by the remote I/O and indicate it with the tower light at the remote location. -
Page 38: Trouble Shooting
JC-IO? HUB and router. Is the JC-IO turned OFF and ON after Turn OFF and ON the power of the JC-IO. setting IP address to the JC-IO? Is the IP address allocated from the Confirm the setting of the using router. -
Page 39: Lan Connection
Connect the LAN cable securely. connected from the HUB? Check the connecting LED of the HUB. Is the POWER LED of the JC-IO ON? Refer to 1.6 Component Identification. Is the IP address overlapping with the Check the IP address of the PC and the PC and the JC-IO? JC-IO. -
Page 40: Slmp (Client)
Are the IP address of the server de- Check the IP address. vice registered by JCIOCFG and the Refer to 4.4.3 C (Connection)) IP address of the JC-IO same? Is the IP address set to the SLMP Enable the server function of the SLMP device? device. -
Page 41: License
8. LICENSE JC-IO-N and JCIOCFG incorporate exPat. Copyright (c) 1998, 1999, 2000 Thai Open Source Software Center Ltd and Clark Cooper Copyright (c) 2001, 2002, 2003, 2004, 2005, 2006 Expat maintainers. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation...
