4.1 General Specifications

The JC-IO is configurable via JCIOCFG.
Downloadable at M-System's web site.
Table 18. JCIOCFG General specifications
Product name
Executable file
PC Requirements
Cennection port
Functions
To use JCIOCFG, a PC configurator cable (COP-US) is required.
Purchase the COP-US with the JC-IO.
A driver software for COP-US is downloadable at M-System web site.
Web server can also configurate same parameters as JCIOCFG without COP-US.
Refer to 5. WEB SERVER for details of web server.

4.2 Version

The software version of the JC-IO can be checked as following.
1. Click

4. JCIOCFG

ITEM
2. Click
DESCRIPTION
PC Configurator Software for JC-IO
JCIOCFG.exe (operable with the exe file only)
Windows 10 (32-bits, 64-bits)
Modular jackRS-232-C (COP-US)
- Download the configurations from the module
- Save the configurations to the file
- Download the configurations from the file
- Send the configurations to the module
- Create new configurations and edit it
JC-IO USERS MANUAL EM-9044-B 17
