13. Spare parts Kits
SAF-X STD Seals set 700194-000066 (applicable for all models)
ITEM
CAT. NO.
NO.
100
770102-000176
101
770104-000403
102
770104-000404
103
770101-000040
104
770104-000400
105
770102-000161
106
770102-000093
Spare parts Kits for annual maintenance
CAT. NO.
700194-000050
700194-000051
700194-000052
700194-000053
700194-000054
700194-000055
Each Kit contains the following items:
SLN SCANNER PREVENTIVE MAINTENANCE ONE YEAR
ITEM NO.
CAT. NO.
26
700190-006190
24+108
700190-002400
107
710101-001281
36
760105-000097
37
760105-000052
ML-2
760190-000127
ML-3
760190-000097
STD SCANNER NOZZLES PREVENTIVE MAINTENANCE ONE YEAR
ITEM NO.
CAT. NO.
26
700190-006190
16+17
710101-000922
222
760101-000537
36
760105-000097
37
760105-000052
ML-2
760190-000127
ML-3
760190-000097
24
DESCRIPTION
O-RING 2-452 70 SHORE
SAF-X SEALING SLEEVE HYDRAULIC SEAL
SAF-X COARSE SCREEN HYDRAULIC SEAL
O-RING 60 X 4 70 SHORE
SAF-X SCREEN HYDRAULIC SEAL
O-RING P 2-370 70 SHORE
O-RING P 2-126 70 SHORE
SAF-X 1500 SLN SCANNER PREVENTIVE MAINTENANCE ONE YEAR
SAF-X 3000 SLN SCANNER PREVENTIVE MAINTENANCE ONE YEAR
SAF-X 4500 SLN SCANNER PREVENTIVE MAINTENANCE ONE YEAR
SAF-X 1500 STD SCANNER NOZZLES PREVENTIVE MAINTENANCE ONE YEAR
SAF-X 3000 STD SCANNER NOZZLES PREVENTIVE MAINTENANCE ONE YEAR
SAF-X 4500 STD SCANNER NOZZLES PREVENTIVE MAINTENANCE ONE YEAR
DESCRIPTION
SAF SHAFT SEALING ASSEMBLY
SLN CAP ASSEMBLY (+O-RING)
SLN SEAL 16 MM TPU
CLEVIS PIN 3/16" X 1-1/16"
PIN COTTER 3/64 X 5/8 MM
TUBE OF GREASE PG-21
SPANJAARD NON-MELTING GREASE 100 GM TUBE
DESCRIPTION
SAF SHAFT SEALING ASSEMBLY
MOLDED SCANNER NOZZLE - PART 1 + 2
PHILLIPS PAN TAP SCREW PT4X20
CLEVIS PIN 3/16" X 1-1/16"
PIN COTTER 3/64 X 5/8 MM
TUBE OF GREASE PG-21
SPANJAARD NON-MELTING GREASE 100 GM TUBE
SAF-X
910101
DESCRIPTION
-
001301
/
01.2022
Installation & Operation Manual
QTY.
MATERIALS
1
NBR
2
EPDM
1
EPDM
1
NBR
2
EPDM
1
NBR
1
NBR
QTY. PER SAF-X MODEL
1500
3000
4500
1
1
1
2
4
6
4
8
12
2
2
2
2
2
2
1
1
1
1
1
1
QTY. PER SAF-X MODEL
1500
3000
4500
1
1
1
2
4
6
8
16
24
2
2
2
2
2
2
1
1
1
1
1
1
