USB-EXT-3-LOCAL and USB-EXT-3-REMOTE
USB 3.2 Extender over CAT 6a/7 Cable, Local and Remote
Observe the LED Indicators
The following table describes the behavior of the LEDs on the front
panel of the USB extender.
LED Color
Power Green
Status Solid green
Flashing green
Link Green
USB 2 Solid green
Flashing green
USB 3 Solid green
Flashing green
LAN Solid green
Flashing green
Description
The USB extender is receiving power.
The USB extender is functioning normally.
The USB extender is powering on.
When flashing in unison with the Link, USB
2, and USB 3 LEDs, the unit is or was
operating at an unsafe temperature. To
Troubleshoot the
resolve this issue, refer to
USB Extender
.
A link has been established between the
local and remote USB extenders.
A USB 2 connection is detected on the USB
port on the USB-EXT-3-LOCAL.
A USB 2 connection on the USB port on the
USB-EXT-3-LOCAL has been suspended or
is in sleep mode.
A USB 3 connection is detected on the USB
port on the USB-EXT-3-LOCAL.
A USB 3 connection on the USB port on the
USB-EXT-3-LOCAL has been suspended or
is in sleep mode.
A link has been established between the
USB extender and the network or network
device.
There is Ethernet activity.

Check the Installation

To check if the USB extender system has been installed correctly on the
host computer, refer to the following instructions.
For Windows Software:
1. Open Device Manager.
2. Expand the Universal Serial Bus controllers node.
3. Check to see if the extender system appears on the list of controllers.
If the extender system has been properly installed, it appears on the
list as a "Generic USB Hub."
For macOS Software:
1. Open System Profiler.
2. In the left column under Hardware, select USB.
3. Check to see if the extender system appears in the USB Device Tree
at the top right of the System Profiler window. If the extender
system has been properly installed, it is listed as a "Hub" under the
USB High-Speed Bus/USB Bus node.
If the USB extender system does not detect correctly or fails to detect,
refer to Troubleshoot the USB
Quick Start
Extender.
