USB-EXT-3-LOCAL and USB-EXT-3-REMOTE
USB 3.2 Extender over CAT 6a/7 Cable, Local and Remote
4. Install any software on the host computer that is required to operate
the USB device(s). Refer to the USB device documentation for
installation instructions.
5. Connect up to four USB Type-A devices (USB 3.2 Gen 1, 2.0, or 1.1
compatible) to the USB-EXT-3-REMOTE. The USB-EXT-3-REMOTE
supports up to 30 USB devices with the connection of up to three
USB hubs (not included).
NOTE: The USB extender is engineered to deliver maximum
compatibility with the widest possible range of devices. Crestron
does not guarantee that all USB devices or hosts are compatible
with the USB extender.
6. (optional) The USB extenders provide functionality for a
pass-through 100BASE-TX/1000BASE-T network connection. To
make a pass-through connection:
TIP: A pass-through network connection can give network access
to remote devices, or it can use existing cabling to offer USB
connectivity without losing network connectivity.
a. Connect the LAN port on the USB-EXT-3-LOCAL to an Ethernet
network using a CAT 5e/6a/7 cable. The maximum cable distance
is 330 ft (100 m).
b. Connect the LAN port on the USB-EXT-3-REMOTE to a
network-enabled device using a CAT 5e/6a/7 cable. The maximum
cable distance is 330 ft (100 m).
