We appreciate your purchase of a TAKEX flame Passive sensor. Please read this instruction manual carefully for correct and effective use.
This sensor is designed to detect flames and/or intrusion and to initiate an alarm; it is not a fire-preventing device.
TAKEX is not responsible for damage, injury or losses caused by accident, theft, Acts of God (including inductive surge by lightning), abuse,
misuse, abnormal usage, faulty installation or improper maintenance.
Do not subject the sensor to a strong impact; it may cause
●
damage, malfunction, or a loss in performance.
Do not handle the unit in a rough manner.
FP-5500E is a combination sensor; integrating flame and passive infrared sensors into one unit.
FP-5500E features two output modes; "AND" detection mode and "Individual" detection mode.
"AND" detection mode initiates flame and passive alarm signal output together when both the flame sensor and passive
infrared sensor detect during the selected time.
"Individual" detection mode initiates flame or passive alarm signal output when either the flame sensor or passive infrared
sensor detects.
There is also a "Forced f lame alarm output" operation.
The flame sensor initiates flame alarm signal after continued detection for a certain period of time even without passive infrared
detection in "AND" detection mode.
（ ）
FLAME PASSIVE SENSOR
Instruction Manual
（
×
：
Intense flames caused by gas explosion etc. may damage the
●
sensor, without detecting the flame.
）
×
①
Advertisement
Related Manuals for Takex FP-5500E
Summary of Contents for Takex FP-5500E
- Page 1 This sensor is designed to detect flames and/or intrusion and to initiate an alarm; it is not a fire-preventing device. TAKEX is not responsible for damage, injury or losses caused by accident, theft, Acts of God (including inductive surge by lightning), abuse, misuse, abnormal usage, faulty installation or improper maintenance.
- Page 2 This indicates the possibility of severe injury, even death, if ignored or a user handles the unit incorrectly This indicates the possibility of minor injury and/or damage to properties, or of a notification delay in your system due to false operations and/or non-detection, if ignored or a user handles the unit incorrectly. Do not touch the wiring leads with wet hands.
- Page 3 Three-part rotation mechanism, as shown below, enables 〔 adjustment in various angles. Adjustable angles may be 〕 limited depending on mounting location and change mounting way if necessary. 〔 〕 ② （ ） ① ③ （ ） 〔 〕 （ ）...
- Page 4 〔 〕 〔 〕 ① ② ① ① ② ② When wiring inside the mounting flange, mount it so that the wiring hole of the flange is at φ the bottom, and take sufficient rainproof φ measures such as caulking around the φ...
- Page 5 The sensor outputs alarm signal when both flame and passive sensors detect during the set AND timer. (ALARM②) In addition, alarm signal will be output even when the flame sensor alone detects twice within the AND timer, or if the flame continues for flame duration time 30 or 60 sec. (ALARM①) * When AND operation is set, the detection sensitivity of the flame sensor is fixed at "H"...
- Page 6 Start actual operation after conf irming that the unit is functioning properly. Solve possible problems according to the following table . If normal operations cannot be restored by these remedies actions, contact either the dealer from whom you bought the unit or TAKEX. ① ①...
- Page 7 ① 【 】 【 】 ② 【 】 【 】 × × ⑦...
- Page 8 Limited Warranty : TAKEX products are warranted to be free from defects in material and workmanship for 12 months from original date of shipment. Our warranty does not cover damage or failure caused by Acts of God (including inductive surge by lightning), abuse, misuse, abnormal usage, faulty installation, improper maintenance or any repairs other than those provided by TAKEX.
