Thank you for your purchase of this TAKEX passive infrared sensor.
This sensor will provide a long and dependable service when properly installed. Please read this Instruction Manual carefully for correct
and effective use.
: This sensor is designed to detect intrusion and to initiate an alarm; it is not a burglary-preventing device. TAKEX is not
responsible for any damage, injury, or loss caused by accident, theft, Acts of God (including lightning), abuse, misuse,
abnormal usage, faulty installation or improper maintenance.
The dual zone outdoor PIR is an automatic switch which uses passive infrared technology to detect infrared emitted from a human (body
temperature). Suitable for indoor/outdoor use, this sensor provides detection coverage of 12 m×180 degrees, with independent outputs for
alarm and external devices per left/right (90 degree) side, adjustable individually.
This indicates the possibility of severe injury, and even death, if ignored or a user handles the unit incorrectly.
Do not disassemble or alter this product.
Immediately stop power supply in the event of abnormal condition.
Do not connect devices which exceed the capacitance of this sensor.
Strictly obseve the specified vlotage (9 to 28V DC).
This indicates the possibility of minor injury and/or damage to properties, or of a notification delay in your system
due to false operations and/or non-detection, if ignored or a user handles the unit incorrectly.
Avoid electrical noise
Avoid spraying water with a
hose
Install perpendicularly
Instruction Manual
A prohibited action, you must not do.
Remove all obstructions
Avoid exhaust vent
Ensure that people cross
the detection area
Follow these mounting condition
An action you must do, and information you should keep in mind.
Mount the sensor securely in an optimal position.
Immediately stop power supply in the event of water entry.
Do not use the sensor in a location with high humidity.
Keep installation height
0.8 to 1.2m(2.6' to 4.0')
Avoid detection of cars/motorcycles on the roadside.
The detection zone extends to 12m ahead; there is a
possibility of detecting vehicles with temperature
differences.
①
Avoid strong light
Remove obstructions, including glass
Advertisement
Related Manuals for Takex MX-12FAM
Summary of Contents for Takex MX-12FAM
- Page 1 : This sensor is designed to detect intrusion and to initiate an alarm; it is not a burglary-preventing device. TAKEX is not responsible for any damage, injury, or loss caused by accident, theft, Acts of God (including lightning), abuse, misuse, abnormal usage, faulty installation or improper maintenance.
- Page 2 （ ） Loosen the cover locking screws and remove the cover. [Embedded wiring ] (1) Align the back of sensor with the wiring from the wall. (2) Feed the wiring through the wiring hole and connect it to the terminals. (3) Use sealant and caulk the gap around the wiring.
- Page 3 * Use the pole attachment BP-32 sold separately. (for pole dia 38mm to 45mm (1.50" to 1.77")) (1) Break off the pole mounting knockouts. (2) Fit the pole mounting brackets to the sensor. (3) Select Active or Inactive Back Tamper by reversing the rubber switch cover. (4) Use sealant to caulk the screw hole and the gap around wiring entry.
-
Page 4: Important Notes
Make necessary area masking Set the pulse count to 1 IMPORTANT NOTES Detection range/sensitivity may change depending on the following factors: ・Small difference of temperature between object and surroundings. ・Movement direction of the object. ・Mounting height. ・Mounting orientation. ・Slope in detection area. Alarm signal is issued only when both horizontal and downward zones detect objects. - Page 5 (1) Pull out the area masking sheet from cover. (2) Bend or cut off the sheet to adjust it to the masking area. (3) Clip the mask to the protruding hooks around the optical unit. - In case of wall detection, set the pulse count to 1. - Carry out a walk test and check the detection area.
-
Page 6: Maintenance
**Monitoring and notification in case input power supply voltage to the sensor is reduced. Solve possible problems according to the following table. If normal operations cannot be restored by this means, contact either the dealer from whom you bought the unit or TAKEX. Trouble... -
Page 7: External Output
Model MX-12FAM Detection system Passive infrared Horizontal detection Angle : 180°, Detection distance : 12m(40') Detection area Horizontal zone : 14 zones Downward zone : 14 zones Detection distance : 2 to 12m(10' to 40') [10 ranges] (by adjusting vertical angle of downward curtain) - Page 8 Limited Warranty : TAKEX products are warranted to be free from defects in material and workmanship for 12 months from original date of shipment. Our warranty does not cover damage or failure caused by Acts of God (including inductive surge by lightning), abuse, misuse, abnormal usage, faulty installation, improper maintenance or any repairs other than those provided by TAKEX.
