Specifications, Parts, and Accessories, cont'd
Compliances .................................... CE, FCC Class A
MTBF ................................................. 30,000 hours
Warranty ........................................... 3 years parts and labor
Specifications are subject to change without notice.
Included Parts
These items are included in each order for a CVEQ1,
CVEQ1 AAP, or CVEQ1 WM:
Included parts
CVEQ1
CVEQ1 AAP
(gray, black, white)
or
CVEQ1 WM (gray, black, white)
or
12VDC, 1A external power supply
CVEQ1/CVEQ1 AAP/CVEQ1 WM
User's Manual
Accessories
Accessories
BNCM-RCAF adapter
3.5 mm 5-pole captive screw connector
AAP 102 2 gang wall plate
AAP 104 4 gang wall plate
AAP 201 half rack width, 1U high faceplate
AAP 202 half rack width, 2U high faceplate
1-gang mounting bracket/mud ring
(gray, black, white)
P/S 100 universal power supply
P/S 150 universal power supply
Cables
Super high resolution cables
SHR-1, 6' (1.8 m), 12' (3.7 m)
SHR-1, 50' (15.2 m), 100' (30.5 m)
SHR-1, 500' (152.4 m) bulk
A-4
CVEQ1, CVEQ1 WM, CVEQ1 AAP • Specifications, Parts, Accessories
(7.4x-081902-D3x)
Part number
60-360-02
70-146-02, -12, -22
60-435-02, -12, -22
28-071-02
68-544-01
Part number
10-264-01
10-319-10
60-300-01,-02,-03
(gray, black, white)
60-301-01,-02,-03
(gray, black, white)
60-302-01
60-303-01
70-086-05, -15, -25
60-357-01
60-432-01
Part number
26-383-12, -07
26-383-05, -03
22-098-02
CVEQ1, CVEQ1 WM, CVEQ1 AAP
Dimensions and Templates
B
A ppendix B
Dimensions
Cut-out Template
