User's Manual
CVEQ 100 Series and
Composite Video or S-Video and Audio Line Drivers
SVEQ 100 Series
with Gain and Equalization
68-1442-01 Rev. C
07 08
Advertisement
Table of Contents
Related Manuals for Extron electronics A-3
Summary of Contents for Extron electronics A-3
- Page 1 Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia 1230 South Lewis Street Beeldschermweg 6C 135 Joo Seng Rd. #04-01 Anaheim, CA 92805 3821 AH Amersfoort, The Netherlands PM Industrial Bldg., Singapore 368363 800.633.9876 714.491.1500 +800.3987.6673 +31.33.453.4040 +800.7339.8766 +65.6383.4400 FAX 714.491.1517 FAX +31.33.453.4050 FAX +65.6383.4664 www.extron.com...
- Page 2 Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source This symbol is intended to alert the user of important indicated on the product. This equipment is intended to be used with a main power operating and maintenance (servicing) instructions in system with a grounded (neutral) conductor.
- Page 3 安全须知 • 中文 这个符号提示用户该设备用户手册中 有重要的操作和维护说明。 这个符号警告用户该设备机壳内有暴 露的危险电压，有触电危险。 注意 阅读说明书 • 用 户 使 用 该 设 备 前 必 须 阅 读 并 理 解 所 有 安 全 和 使 用 说 明 。 保存说明书 • 用户应保存安全说明书以备将来使 用。 遵守警告 • 用户应遵守产品和用户指南上的所有安 全和操作说明。...
- Page 4 Quick Start Guide — CVEQ/SVEQ 100 Series Installation and service must be performed by authorized personnel only. These line drivers must be used with UL approved, grounded electrical boxes. To install and set up the line driver, follow these steps and see the appropriate sections of this manual for details.
-
Page 5: Table Of Contents
Quick Start — CVEQ/SVEQ 100 Series, cont’d When using long cables, follow these steps: Supply the color bars test signal to the input. (Recommendation: use an Extron VTG 300 Video Test Generator to generate the test signal.) Adjust the Gain control(s) for the output until the signal level at the far end is the same as the input (or the display shows the correct brightness and contrast). -
Page 6: About This Manual
Table of Contents, cont’d Appendix B • Dimensions and Template Decora Models Dimensions ... B-2 Cut-out Template ... B-3 All trademarks mentioned in this manual are the properties of their respective owners. TOC-ii CVEQ 100 and SVEQ 100 Series • Table of Contents ... -
Page 7: Application Examples
Stereo or dual mono output selector switch — A rear panel switch selects between stereo and dual mono output formats (D, AAP, and MAAP models only). -
Page 8: Application Examples
Installation Application Examples To get started, refer to the "Quick Start Guide" at the beginning of this manual. Installation and service must be performed by authorized personnel only. 0. 2A Extron SVEQ 100 S-Video Line Driver SVEQ 100 application example Extron SI 26X Two-way Ceiling... -
Page 9: Installation Instructions
For tabletop use, attach one foot at each corner of the bottom side of the unit and place the unit in the desired location. See chapter 3 for details on wiring and switch settings. UL rack mounting guidelines The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the line drivers in a rack. -
Page 10: Furniture Mounting - Under-Desk
Installation 1U Universal Rack Shelf Both front false faceplates use 2 screws. Use 2 mounting holes on opposite corners. Mounting the line driver on a standard rack shelf 6" Deep Rack Shelf 1/2 Rack Width Front False Faceplate Front false faceplate uses 2 screws. -
Page 11: Back Of The Rack Mounting (Sveq 100 Only)
Installation Preparing the CVEQ 100 for through-desk mounting If rubber feet were previously attached to the bottom of the unit, remove them. Attach the mounting brackets to the CVEQ 100 with the provided machine screws as shown in the previous figure. Hold the unit with the attached brackets against the underside of the table or other furniture. -
Page 12: Installing The Cveq 100 Aap/Sveq 100 Aap
Installation, cont’d SVEQ 100 back of the rack installation example CVEQ 100 and SVEQ 100 Series • Installation 2-10 Inside Outside Installing the CVEQ 100 AAP/SVEQ 100 AAP The CVEQ 100 AAP and SVEQ 100 AAP are double space high architectural adapter plate products that mount in a wall or furniture using an optional mounting frame. -
Page 13: Installing The Cveq 100 Maap/Sveq 100 Maap
Installation, cont’d Installing the CVEQ 100 MAAP/SVEQ 100 MAAP The CVEQ 100 MAAP and SVEQ 100 MAAP are three space high mini architectural adapter plate products that mount in a wall or furniture using an optional mounting frame or European cable channel system. -
Page 14: Installing The Cveq 100 D/Sveq 100 D
If the system is operating correctly, the line driver can be installed in the wall. Adjust the gain and equalization, and set the Audio Out switch to Stereo or Dual Mono before fastening the line driver into the wall box. The controls and cables will be inaccessible after installation. -
Page 15: Testing And Troubleshooting
Installation, cont’d Mount the line driver to the wall box with machine screws as shown in the following illustration. Wall Box Wall opening is flush with edge of box. Mounting the line driver to a wall box Attach the Decora ®... -
Page 16: Chapter Three • Operation
Installation, cont’d CVEQ 100 and SVEQ 100 Series Chapter Three Operation Front Panel Features and Operation Rear Panel Features and Operation Replacing the Decora Faceplate (CVEQ 100 D and SVEQ 100 D) CVEQ 100 and SVEQ 100 Series • Installation 2-18... -
Page 17: Front Panel Features And Operation
Operation Front Panel Features and Operation GAIN GAIN GAIN V ID E O A U D IO IN C V E Q 100 A A P S-V ID E O A U D IO IN S V E Q 100 A A P CVEQ 100 and SVEQ 100 Series •... - Page 18 Operation Power indicator LED — This LED lights: • Amber when the line driver is receiving full power (this applies to all models except the CVEQ 100 and SVEQ 100, which light green instead). • Green when the line driver is receiving a video signal (this only applies to the D, AAP, and MAAP models).
-
Page 19: Rear Panel Features And Operation
Operation Rear Panel Features and Operation INPUT 0.2A MAX VIDEO CVEQ 100 Rear Panel INPUT 0.2A MAX SVEQ 100 Rear Panel CVEQ 100 AAP Rear Connectors CVEQ 100 and SVEQ 100 Series • Operation OUTPUT VIDEO OUTPUT SVEQ 100 AAP Rear Connectors CVEQ 100 AAP Audio Output Wiring To compensate for image degradation... - Page 20 Operation, cont’d CVEQ 100 MAAP Rear Panel SVEQ 100 MAAP Rear Panel CVEQ 100 and SVEQ 100 Series • Operation P O W E R 1 2V 0 .2 A M A X P O W E R 1 2V 0 .2 A M A X CVEQ 100 D Rear Panel SVEQ 100 D Rear Panel...
-
Page 21: Power Supply Wiring
(the dot position). See "Gain adjustment control" in this chapter. Audio output select switch — Use this switch to select either stereo (up) or dual mono (down) output. When set for dual mono, the left and right channels output the same signal (either channel or both channels can be used). -
Page 22: Gain Adjustment Control
Operation, cont’d Power supply voltage polarity is critical. Incorrect voltage polarity can damage the power supply and the line driver. Identify the power cord negative lead by the ridges on the side of the cord. To verify the polarity before connection, plug in the power supply with no load and check the output with a voltmeter. - Page 23 Operation, cont’d CVEQ 100 and SVEQ 100 Series A ppendix A Specifications, Part Numbers, and Accessories Specifications Included Parts Optional Accessories CVEQ 100 and SVEQ 100 Series • Operation 3-14...
-
Page 24: Appendix A • Specifications, Part Numbers, And Accessories
Specifications, Part Numbers, and Accessories Specifications Video Gain ... Composite video and Y of S-video: -1 dB to +3 dB (x0.9 to x1.4), adjustable C of S-video: 0 dB to +10 dB (x1 to x3), adjustable Equalization ... 0 dB to +7 dB (x1 to x2) at 5 MHz, adjustable Bandwidth (Y of S-video)... -
Page 25: Audio Output
Specifications, Part Numbers, Accessories, cont’d Audio output Number/signal type CVEQ 100, SVEQ 100... 1 stereo, balanced/unbalanced All other models... 1 stereo or dual mono (switch-selectable), balanced/unbalanced Connectors ... (1) 3.5 mm captive screw connector, 5 pole Impedance... 50 ohms unbalanced, 100 ohms balanced Nominal level ... -
Page 26: Included Parts
Specifications, Part Numbers, Accessories, cont’d Shipping weight CVEQ 100, SVEQ 100... 3 lbs (2 kg) All other models... 2 lbs (1 kg) Vibration... ISTA 1A in carton (International Safe Transit Association) Listings... UL, CUL Compliances... CE, FCC Class A, VCCI, AS/NZS, ICES MTBF... -
Page 27: Optional Accessories
Specifications, Part Numbers, Accessories, cont’d These items are included in each order of the CVEQ 100 MAAP or SVEQ 100 MAAP. Included parts CVEQ 100 MAAP (black) or SVEQ 100 MAAP (black) or CVEQ 100 MAAP (white) or SVEQ 100 MAAP (white) or CVEQ 100 MAAP (RAL9010) or SVEQ 100 MAAP (RAL9010) User's manual... - Page 28 Specifications, Part Numbers, Accessories, cont’d These items are optional accessories for the CVEQ 100 D or SVEQ 100 D. Accessory MHR-2 mini high resolution non-plenum cable, bulk MHR-2P mini high resolution plenum cable, bulk RG59 high resolution non-plenum cable, bulk RG59P high resolution plenum cable, bulk RG6 super high resolution non-plenum...
-
Page 29: Decora Models Dimensions
Specifications, Part Numbers, Accessories, cont’d CVEQ 100 and SVEQ 100 Series A ppendix B Dimensions and Template Decora Models Dimensions Cut-out Template CVEQ 100 and SVEQ 100 Series • Specifications and Parts A-12... -
Page 30: Cut-Out Template
Dimensions and Template Decora Models Dimensions Dimensions are shown in inches [mm}. .060 [1.524] .600 [15.500] .100 [2.540] 2.830 [71.882] 2.720 [69.088] 2.040 [51.816] 1.465 [37.211] 0.790 [20.066] 0.110 [2.794] 0.000 [0.000] Front View CVEQ 100 and SVEQ 100 Series • Dimensions and Template 0.000 [0.000] 2.720 [70.000] Side View... - Page 31 Dimensions and Template CVEQ 100 and SVEQ 100 Series • Dimensions and Template...
