Installation, Setup, Operation, cont'd
CVEQ1, CVEQ1 WM, CVEQ1 AAP • Installation, Setup, Operation
Rear/Bottom/Side Panel Features and Cabling
CVEQ1
Rear Panel
AUDIO OUTPUT
VIDEO OUTPUT
POWER
L
R
1
2
3
CVEQ1 WM
Side Panel
3
1
2
CVEQ1, CVEQ1 WM, CVEQ1 AAP • Installation, Setup, Operation
CVEQ1 AAP
Bottom Panel
1
J6
J2
1
L
L
R R
3
1
2
Audio output connector —
1
Cable an audio device to the line
driver via this female 5-pole
captive screw connector. Wire the
male connector as shown below.
Unbalanced Audio Output
Tip
See Caution
Sleeve (s)
Tip
See Caution
CAUTION
Connect the sleeve to ground
(Gnd). Connecting the sleeve to
a negative (–) terminal will
damage the audio output circuits.
Balanced Audio Output
Tip
Ring
Sleeve (s)
Tip
Ring
