User's Manual
CVEQ1, CVEQ1 WM, CVEQ1 AAP
1-Input, 1-Output Equalizing Composite Video Line Drivers
68-544-01 Rev. B
Printed in the USA
08 02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CVEQ1 AAP and is the answer not in the manual?

Questions and answers

Summary of Contents for Extron electronics CVEQ1 AAP

  • Page 1 User’s Manual 1-Input, 1-Output Equalizing Composite Video Line Drivers Extron Electronics, Japan Daisan DMJ Building 6F 3-9-1 Kudan Minami Chiyoda-ku, Tokyo 102-0074 Japan +81.3.3511.7655 Fax +81.3.3511.7656 CVEQ1, CVEQ1 WM, CVEQ1 AAP 68-544-01 Rev. B Printed in the USA 08 02...
  • Page 2: Fcc Class A Notice

    Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main operating and maintenance (servicing) instructions power system with a grounded (neutral) conductor.
  • Page 3: Table Of Contents

    Appendix B • Dimensions and Templates Dimensions ... B-2 Cut-out Template ... B-3 All trademarks mentioned in this manual are the properties of their respective owners. CVEQ1, CVEQ1 WM, CVEQ1 AAP • Table of Contents ... 1-2 ... 2-1 ... 2-3 ... 2-6 ... 2-7 ...
  • Page 4: Chapter 1 • Introduction

    Table of Contents, cont’d CVEQ1, CVEQ1 WM, CVEQ1 AAP Chapter One Introduction About the CVEQ1, CVEQ1 WM, and CVEQ1 AAP Features CVEQ1, CVEQ1 WM, CVEQ1 AAP • Table of Contents...
  • Page 5: About The Cveq1, Cveq1 Wm, And Cveq1 Aap

    The Extron CVEQ1 AAP is identical to the CVEQ1, except that it is designed to be mounted in a double-space height architectural adapter plate bracket (in a device’s faceplate or in an AAP wallplate) for installation into a wall or furniture.
  • Page 6: Installation Overview

    You may need to install the cables into the wall, furniture, or conduits before installing the line driver. • The CVEQ1 AAP can be installed in an Extron two-gang, four- gang, or half rack width AAP Architectural Adapter Plate or in the faceplate of another Extron device that accepts AAP plates, such as an interface or distribution amplifier.
  • Page 7 Exposed cable shields (braids or foil) are potential sources of short circuits. Trim back and/or insulate shields with heat shrink. CVEQ1, CVEQ1 WM, CVEQ1 AAP • Installation, Setup, Operation cut-out template that opening...
  • Page 8: Rear/Bottom/Side Panel Features And Cabling

    Installation, Setup, Operation, cont’d CVEQ1, CVEQ1 WM, CVEQ1 AAP • Installation, Setup, Operation Rear/Bottom/Side Panel Features and Cabling CVEQ1 Rear Panel AUDIO OUTPUT VIDEO OUTPUT POWER CVEQ1 WM Side Panel Audio output connector — Cable an audio device to the line driver via this female 5-pole captive screw connector.
  • Page 9: Top/Side Panel Features And Adjustments

    Installation, Setup, Operation, cont’d The CVEQ1 WM and CVEQ1 AAP have a female captive screw connector instead of a jack for connecting an external Positive power source. Wire the power connection as shown Negative at right. CVEQ1, CVEQ1 WM, CVEQ1 AAP • Installation, Setup, Operation...
  • Page 10: Mounting The Cveq1 Aap

    2-10 CVEQ1 Mounting the CVEQ1 AAP The CVEQ1 AAP and any other adapter plates must be attached to a device’s faceplate or an AAP wallplate and cabled before the device or wallplate is installed in a wall or furniture. The screws needed for installing the CVEQ1 AAP are built into its front panel, so no additional screws will be needed.
  • Page 11: Mounting The Cveq1 Wm

    Wall Stud Installation Cable Cable Clamp Mounting the CVEQ1 WM into a wall box 2-12 CVEQ1, CVEQ1 WM, CVEQ1 AAP • Installation, Setup, Operation V ID D IO D IO CVEQ1, CVEQ1 WM, CVEQ1 AAP A ppendix A...
  • Page 12 Number/signal type ... 1 stereo, balanced/unbalanced Connectors CVEQ1 ... 1 3.5 mm captive screw connector, 5 pole CVEQ1 AAP ... 1 3.5 mm direct insertion captive screw connector, 5 pole Impedance ... 50 ohms unbalanced, 100 ohms balanced Nominal level ... -2dBu (632mV), balanced output Maximum level (600 ohm) ...
  • Page 13 Cables Super high resolution cables SHR-1, 6’ (1.8 m), 12’ (3.7 m) SHR-1, 50’ (15.2 m), 100’ (30.5 m) SHR-1, 500’ (152.4 m) bulk CVEQ1, CVEQ1 WM, CVEQ1 AAP • Specifications, Parts, Accessories (7.4x-081902-D3x) Part number 60-360-02 70-146-02, -12, -22...
  • Page 14: Appendix B • Dimensions And Templates

    0.050 DEEP (FAR SIDE) R AUDIO IN ø 0.125 THRU WITH ø 0.220 X 82˚ CVEQ1 WM C'SINK NEAR SIDE (2 PLACES) CVEQ1, CVEQ1 WM, CVEQ1 AAP • Dimensions, Templates R 0.250 0.100 (4 PLACES) 4.500 3.890 3.700 3.410 3.160 2.720 2.024...
  • Page 15 Dimensions, Templates, cont’d CVEQ1, CVEQ1 WM, CVEQ1 AAP • Dimensions, Templates...

This manual is also suitable for:

Cveq1 wmCveq1

Table of Contents
