3-Color Display
IO-Link Compatible PF2MC7 -
Supports the IO-Link communication protocol
PLC
Fieldbus
Device settings can be
set by the master.
• Threshold value
• Operation mode,
etc.
IO-Link Master
Implement diagnostic bits in the process data.
The diagnostic bit in the cyclic process data makes it easy to find problems with the equipment.
It is possible to find problems with the equipment in real time using the cyclic (periodic) data and to monitor such problems in detail with the noncyclic (aperiodic) data.
Process Data
Bit offset Item
0 OUT1 output 0: OFF
1 OUT2 output 0: OFF
8 Flow rate diagnosis 0: OFF
14 Fixed output 0: OFF
15 Error (Failure) 0: OFF
16 to 31 Measured flow rate value Signed 16 bit
Bit offset 31 30 29 28
Item
Bit offset 15 14 13 12
Item Reservation
Error Fixed
(Failure) output
Display function
Displays the output communication
status and indicates the presence of
communication data
Operation and Display
Communication IO-Link status
with master indicator light
*
1
Yes
IO-Link
*
1
mode
(Flashing)
No
OFF
*1 In IO-Link mode, the IO-Link indicator is ON or flashing.
* "ModE LoC" is displayed when the data storage lock is enabled. (Except for when the version does not match or when in SIO mode)
3-Screen Display
Configuration File (IODD File *
· Manufacturer · Product part no. · Set value
*1 IODD File:
I O D D i s a n a bb r ev i a t i o n o f I O D ev i c e
Description. This file is necessary for setting
PC
the device and connecting it to a master. Save
the IODD file on the PC to be used to set the
device prior to use.
Read the device data.
• Switch ON/OFF signal and analog value
• Device information:
Manufacturer, Product part number, Serial number, etc.
• Normal or abnormal device status
• Cable breakage
Note
Diagnosis items
1: ON
• Over current error
1: ON
• Above the rated flow range
1: ON
• Above the accumulated flow range
• Below the rated flow range
1: ON
• Below the accumulated flow range
1: ON
• Internal product malfunction
27 26 25 24 23 22 21
Measured flow rate value (PD)
11 10 9 8 7 6
Reservation
Flow rate
diagnosis
SIO mode
Screen
Status
display *
Operate
Start up
Preoperate
Version does
not match
Communication
disconnection
SIO mode
*2 When the lower line (sub screen) is set to mode display
Digital Flow Switch
-L -
20 19 18 17 16
5 4 3 2 1 0
OUT2 OUT1
Switch output
Start-up mode Preoperate mode
2
Normal communication status (readout of measured value)
At the start of communication
The IO-Link version does not match that of the master.
* The applicable IO-Link version is 1.1.
Normal communication was not received for 1 s or longer.
PF2MC7(-L)
IO-Link is an open communication interface
1
)
technology between the sensor/actuator
and the I/O terminal that is an international
standard: IEC 61131-9.
IO-Link Compatible Device:
Digital Flow Switch for Air
Application Example
For the control of air consumption For the control of air consumption
Main line flow control
Can be used for the flow control,
etc., of the main line and branch
lines
The instantaneous flow, set value,
and accumulated value can be
Flow control for
checked at the same time.
each branch line
Operate mode
Description
General switch output
Series
10
p.
M/C
M/C
M/C
