Materials Included:
Part #
Description
1
3 1/2" sq.. x 58" Posts
2
1 3/4" sq. x 36 3/4" Top
3
1 3/4" sq. x 36 3/4" Middle rail
4
7/8" x 1 1/2" x 19 5/8" Spokes
5
7/8" x 1 1/2" x 15 5/8" Spokes
6
1 3/4" sq x 36 3/4" Bottom rail
7
Keystone
8
Arches
9
7/8" x 1 1/2" x 43 1/4" side spindle 5
10
Hardware kit (Includes):
3/4" Self-tapping stainless screws
Materials (Optional):
- Pre-mix concrete
(recommended for added stability).
- Pressure treated 2x4 or 4x4 2 ft long ripped to
3" wide
30"
(Fig. 2)
Post layout for installation.
Hanover Trellis
Assembly & Mounting Instructions
General Information:
- Read instructions through carefully before
beginning assembly.
- Identify each component from material list.
- When assembling components, place on a
non-abrasive surface to avoid scratches.
- Do not use excessive force when assembling
components.
- In the event of missing or defective parts,
please call our customer service department
at 1-800-282-9346 (ext.#20).
Tools Required:
- Cordless drill with #2 Robertson
Quantity
bit
2
- Tape measure
1
- Level
3
- Shovel
2
- Pencil
2
1
1
1
8
(Fig. 1)
Product dimensions & part
identification.
Ver 1.07
