CLEANUP

Step 1: Perform Pressure Relief Procedure. Step 2: Drain remaining material into a bucket until most of
the texture material is out of hopper. Step 3: Fill hopper with clean water. Step 4: Remove nozzle from gun.
Trigger gun into bucket until most of texture mix is out of the hopper. Allow water to flow through gun until
gun is clean. Step 5: Open gun air flow valve, allowing air through nozzle to clear out any remaining material.
Step 6: Disconnect spray gun from air hose. Step 7: Remove hopper gun and finish cleaning all
components. A soft brush may be used to help loosen any dried material from the surface. Step 8: Check
air relief valve. If sticky or contaminated with material, disassemble and clean. Grease o-rings and
reassemble. Step 9: Clean hopper air passageway and air supply tube. Step 10: Connect air hose to gun.
Step 11: Turn air compressor ON. Step 12: Open gun air flow valve to allow air flow through the needle
to clear out remaining material. Perform Pressure Relief Procedure. Step 13: If trigger feels sticky,
lubricate needle seals.
