Directed Directechs DS4+ Installation Manual page 12

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Function
Ford Fusion (Key) 2013-2016
Parking Lights
Parking Lights Interrupt
12V
Ground
HS CAN 1 High (w/o OEM Remote Start)
HS CAN 1 Low (w/o OEM Remote Start)
HS CAN 2 High
HS CAN 2 Low
MS CAN High (w/ OEM Remote Start)
MS CAN Low (w/ OEM Remote Start)
Ford Fusion (Smart Key) 2013-2017
Parking Lights
Parking Lights Interrupt
12V
Ground
HS CAN 1 High (w/o OEM Remote Start)
HS CAN 1 Low (w/o OEM Remote Start)
HS CAN 2 High
HS CAN 2 Low
MS CAN High (w/ OEM Remote Start)
MS CAN Low (w/ OEM Remote Start)
12
Wire Information
Color
Gray or Yellow
Black/Blue
Gray/Red
Black/Blue
Green
Gray
White/Blue or Blue
White
Gray/Orange
Violet/Orange
Gray or Yellow
Black/Blue
Gray/Red
Black/Blue
Green
Gray
White/Blue or Blue
White
Gray/Orange
Violet/Orange
Pin Polarity Location
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module at OBDII.
14 (-) Gateway module at OBDII.
18 Data Gateway module at OBDII.
17 Data Gateway module at OBDII.
20 Data Gateway module at OBDII.
19 Data Gateway module at OBDII.
23 Data Gateway module at OBDII.
22 Data Gateway module at OBDII.
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module at OBDII.
14 (-) Gateway module at OBDII.
18 Data Gateway module at OBDII.
17 Data Gateway module at OBDII.
20 Data Gateway module at OBDII.
19 Data Gateway module at OBDII.
23 Data Gateway module at OBDII.
22 Data Gateway module at OBDII.
Connector Information
Color Pins
Black 16
Black 16
Black 24
Black 24
Black 24
Black 24
Black 24
Black 24
Black 24
Black 24
Black 16
Black 16
Black 24
Black 24
Black 24
Black 24
Black 24
Black 24
Black 24
Black 24
DS4+ FORD11
© 2017-05-08 Directed. All rights reserved.
Ref.
A
A
B
B
B
B
B
B
B
B
A
A
B
B
B
B
B
B
B
B
