Analog Devices EVAL-ADAQ23875FMCZ User Manual page 25

EVAL-ADAQ23875FMCZ
Qty Reference Designator
16 R36, R40, R41, R42, R61, R62,
R63,R64, R65, R66, R67, R68,
R69, R70, R71, R72
1 R37
1 R38
1 R39
1 R44
1 R45
1 R46
1 R47
3 R53, R58, R60
1 R54
2 R56, R57
1 R74
1 R76
1 R79
1 R80
1 R84
1 T1
1 U1
1 U2
1 U10
1 U11
2 U9, U12
1 U13
1 U14
1 U3
1 U4
1 U5
1 U6
1 U7
1 U8
2 VIN+, VIN−
1 Y1
10 +2P5V, +5V, +6P5V, +7V,
−2P5V, −2V, 3P3VAX, TP15,
TSTMOD, TSTPAT
7 C24, C25, C29, C39, C40
2 C15, C16
4 C5, C6, C79, C80
3 J1, J2, J4
14 R1, R2, R4, R5, R12, R23, R31,
R32, R49, R85, R86, R89, R90,
R91, R92,
4 R17, R18, R19, R20
1 R3
4 R43, R75
6 R55, R59, R77, R78, R81, R82
2 R6,R8
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
User Guide
Description
0 Ω resistor precision thick film chip
137 kΩ resistor precision thick film chip
30.1 kΩ resistor precision thick film chip, R0603
75 kΩ resistor precision thick film chip, 0603
649 kΩ resistor precision thick film chip
210 kΩ resistor precision thick film chip
953 kΩ resistor precision thick film chip, 0805
200 kΩ resistor precision thick film chip
33 Ω resistor precision thick film chip, 0603
49.9 Ω resistor precision thick film chip, R0603
1 kΩ resistor precision thick film chip, R0603
4.12 kΩ resistor precision thick film chip
Do not install
10 Ω resistor precision thick film chip, R0603
91 Ω resistor precision thick film
2.4 kΩ resistor precision thick film chip, R0603
Transformer RF 1:1
16-bit, 15 MSPS µModule data acquisition
CMOS 3 V/5 V wide bandwidth, quad 2:1 mux
TTL FF D-type positive edge
Low voltage, dual supply 2-bit signal translator
CMOS tiny logic high speed inverter
800 MHz clock distribution
2 kB serial I 2 C bus EEPROM, 1.8 V to 5.5 V
Ultra low noise, high accuracy voltage reference
Low noise, CMOS LDO linear regulator
0.25 ppm noise, low drift precision reference,
4.096 V out
Dual SEPIC, inverting µModule dc-to-dc converter
Ultra low noise, high PSRR, LDO, adjustable
voltage output
LDO, low noise, micropower regulator
Connector PCB end launch SMA edge mount
Crystal ultra low phase noise oscillator
Connector PCB test point, red
Do not install
0.1 µF ceramic capacitor, X7R
Do not install
Connector PCB straight SMA die cast
Do not install, 0 Ω resistor precision thick film
chip, 0603
82 Ω resistor precision thick film chip
Do not install
Do not install
10kΩ resistor precision thick film chip R0603
0Ω resistor precision thick film chip
Rev. 0 | Page 25 of 26
Part No. Manufacturing
MC00625W040210R Multicomp
MC0063W06031137K Multicomp
ERJ-3EKF3012V Panasonic
ERJ-3EKF7502V Panasonic
ERJ-2RKF6493X Panasonic
CPF0402B210KE1 TE Connectivity
9C08052A9533FKHFT Yageo
ERJ-2RKF2003X Panasonic
MC0.063W06031%33R. Multicomp
ERJ-3EKF49R9V Panasonic
ERJ-3EKF1001V Panasonic
ERJ-2RKF4121X Panasonic
TBD0402 Panasonic
ERJ-3EKF10R0V Panasonic
RC0603FR-0791RL Yageo
ERJ-3EKF2401V Panasonic
MABA-007159-000000 Macom Technology
Solutions
ADAQ23875BBCZ Analog Devices
ADG774ABCPZ Analog Devices
NL17SZ74USG ON Semiconductor
FXL2TD245L10X ON Semiconductor
NC7S04M5X Fairchild
Semiconductor
AD9513BCPZ Analog Devices
M24C02-RMN6TP ST Micro Electronics
ADR4520ARZ Analog Devices
ADP7118AUJZ-2.5-R7 Analog Devices
LTC6655BHMS8-4.096#PBF Analog Devices
LTM8049EY#PBF Analog Devices
ADP7183ACPZN-R7 Analog Devices
LT3023IDD#PBF Analog Devices
142-0761-841 Cinch Connectivity
Solutions
CCHD-575-50-100.000 Crystek Corporations.
5000 Keystone Electronics
TBD0402 TBD
06035C104J4Z2A AVX Corporation
TBD0603 TBD
5-1814832-2 TE Connectivity LTD
MC0603WG00000T5E-TC Multicomp
RGH1608-2C-P-820-B Susumu CO, LTD
TBD0603 TBD
TBD0402 TBD
ERJ-3EKF1002V Panasonic
MC00625W040210R Multicomp
UG-1896
