DEMO MANUAL DC1791A

pArts list

ITEM QTY REFERENCE
Required Circuit Components
1 1 U1
Hardware/Components (For Demo Board Only)
2 1 C1
3 1 C2
4 2 C3, C4
5 2 J1, J2
6 2 J1, J2
7 1 JP1
8 1 JP1
9 1 R1
10 1 R2
11 1 R3
12 1 R4
13 2 R6, R7
6
PART DESCRIPTION
–A I.C., LTM2887CY-3S
–B I.C., LTM2887CY-5S
–C I.C., LTM2887CY-3I
–D I.C., LTM2887CY-5I
CAP ., TANT 10μF 10V 20% 1206
CAP ., CER 1μF 10V 20% 0508
CAP ., CER 470pF 250Vac 10% 1808
0.1" DOUBLE ROW HEADER, 5 × 2 PIN
0.1" FERRITE PLATE, 5 × 2 HOLE
Header, 1 × 3 2mm
SHUNT, 1 × 2 2mm
–C RES., CHIP 10kΩ 1% 0805
–D RES., CHIP 10kΩ 1% 0805
–C RES., CHIP 10kΩ 1% 0805
–D RES., CHIP 10kΩ 1% 0805
–C RES., CHIP 0 0805
–D RES., CHIP 0 0805
–A RES., CHIP 0 0805
–B RES., CHIP 0 0805
RES., CHIP 1.15kΩ 1% 0805
MANUFACTURER/PART NUMBER
LINEAR LTM2887CY-3S#PBF
LINEAR LTM2887CY-5S#PBF
LINEAR LTM2887CY-3I#PBF
LINEAR LTM2887CY-5I#PBF
AVX TAJA106M016RNJ
MURATA LLL219R71A105MA01L
MURATA GA342QR7GF471KW01L
SAMTEC TSW-105-22-G-D
FAIR RITE 2644247101
WURTH 62000311121
WURTH 60800213421
YAGEO RC0805FR-0710KL
YAGEO RC0805FR-0710KL
YAGEO RC0805FR-0710KL
YAGEO RC0805FR-0710KL
YAGEO RC0805FR-070RL
YAGEO RC0805FR-070RL
YAGEO RC0805FR-070RL
YAGEO RC0805FR-070RL
YAGEO RC0805FR-071K15L
