Installation & Operations Guide - SmartSource Micro Elite IJ
See below for Micro Elite IJ Models starting with serial # 9203XXXXX
Below is a chart for LED power button indication/function for Micro Elite models starting with serial # 9203XXXX:
LED COLOR
RED
RED
RED
RED
BLUE
BLUE
BLUE
BLUE
PURPLE
RED/PURPLE
PURPLE
PURPLE
PURPLE
Rev. D
Status Light Indication/Function Chart
LED
STATE
SOLID
USB or Ethernet cable not connected
BLINKING Scanner error
SLOWLY
BLINKING Application generated error
RAPID
BLINKING Serious Scanner error (Cycle Power on Scanner)
SLOWLY
BLINKING Cable is connected
BLINKING Application is connected; Scanner is Idle
SOLID Scanner is ready to scan or is Actively Scanning
RAPID 1. Press power button down 6 sec. = Scanner OFF
BLINKING 2. Press power button down 1 sec. & Release = Motors ON (Clear Track)
RAPID In Cleaning Mode (Press/Release Power Button 3 times to enter this
BLINKING mode)
SLOWLY
BLINKING USB or Ethernet cable not connected; Cleaning Required
SLOWLY
BLINKING Cable is connected; Cleaning Required
BLINKING Application is connected; Cleaning Required
SOLID Actively Scanning; Cleaning Required
