850 nm Fiber Isolator

Chapter 6 Specifications

Item #
Polarization
Fiber Type
Center Wavelength
Operating Range
Weight
Optical Specifications
Isolation @ 850 nm
a
Max Power
Insertion Loss (Without Connectors)
Polarization Dependent Loss (PDL)
Return Loss
a) The maximum power specification represents the maximum power for the combined forward and
reverse directions. Therefore, the sum of the powers in the forward and reverse directions cannot
exceed the maximum power specification.
Page 6
Chapter 6: Specifications
IO-F-850
Independent
Single Mode (SM), 780HP
850 nm
840 - 860 nm
0.92 kg
33 dB (Min)
36 dB (Typ.)
2 W (CW)
1.0 dB (Typ.)
1.2 dB (Max)
≤ 0.25 dB
≥ 50 dB
17189-D02
