I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
XSM
FUSION EXTRA LARGE HEIGHT ADJUST
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
FLAT PANEL MOUNTS
XSM/XTM Series
XTM
Advertisement
Related Manuals for CHIEF XSM Series
Summary of Contents for CHIEF XSM Series
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Installationsanleitung Instruções de Instalação FUSION EXTRA LARGE HEIGHT ADJUST Istruzioni di installazione Installatie-instructies Instructions d´installation FLAT PANEL MOUNTS XSM/XTM Series...
-
Page 2: Installation Instructions
XSM/XTM Series DISCLAIMER Milestone AV Technologies, and its affiliated corporations and subsidiaries (collectively "Milestone"), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product. - Page 3 Installation Instructions DIMENSIONS MAX MOUNTING PATTERN IS 46" (1168.4 mm) WITHOUT REVERSING UPRIGHTS 24.3 MINIMUM UPRIGHT SPACING 25.4 1.00 44.5 1.75 RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET 1232.7 48.53 MINIMUM UPRIGHT SPACING 24" 24.4 25.4 1.00 44.5 1.75 RAILS CAN BE SLID LEFT OR RIGHT FOR OFFSET...
- Page 4 XSM/XTM Series LEGEND Tighten Fastener Apretar elemento de fijación Befestigungsteil festziehen Apertar fixador Serrare il fissaggio Bevestiging vastdraaien Serrez les fixations Loosen Fastener Aflojar elemento de fijación Befestigungsteil lösen Desapertar fixador Allentare il fissaggio Bevestiging losdraaien Desserrez les fixations Phillips Screwdriver Destornillador Phillips Kreuzschlitzschraubendreher Chave de fendas Phillips...
-
Page 5: Tools Required For Installation
Installation Instructions TOOLS REQUIRED FOR INSTALLATION 7/32" (5.5mm) Wood Stud 5/16" (7.9mm) Concrete PARTS [Included with XSM2XXX/XTM2XXX J (1) [Used on XSMU/XTMU Models Only] Models Only] Custom XSM2XXX/ XTM2XXX Hardware A (1) J2 (6) J1 (6) M6x25mm M6x16mm J3 (6) J4 (6) M8x20mm M8x30mm... - Page 6 XSM/XTM Series INSTALLATION The XTM and XSM have been designed to be mounted directly onto either a wood stud or concrete wall. The XTM has brackets which allow the display to be tilted. The XSM has static brackets which keep the display in an upright position. Locate Mounting Site WARNING: IMPROPER INSTALLATION CAN LEAD TO...
- Page 7 Installation Instructions (K3) x 4 Figure 2 Mark the attachment points for the lower mounting slots, making sure the attachment points are located on the studs. (See Figure 2) Drill 7/32" pilot holes at markings for lower mounting holes. (See Figure 2) 10.
- Page 8 XSM/XTM Series Center of bracket Figure 4 WARNING: IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! Using screws of improper size may damage your display. Properly sized screws will easily and completely thread into display mounting holes.
- Page 9 Installation Instructions Knobs to outside of brackets Figure 6 Attaching Screen to Wall Mount Attach wall bracket caps (H) to top and bottom of both wall brackets. (See Figure 7) (H) x 4 Figure 7 Adjust Velcro® pull strap (if necessary) so it does not extend beyond bottom of screen.
- Page 10 XSM/XTM Series Proceed to Adjusting Roll/Height of Wall Brackets section. (Screen not shown for clarity) Pull straps Figure 9 XSM Model Push interface bracket tab all the way down so that the lower mounting slot is blocked. (See Figure 10) Latch open Interface...
- Page 11 Installation Instructions XSM/XTM Series Locking XSM Mount (Optional) Add padlock (not included) to interface bracket tab to lock the XSM mount. (See Figure 13) Add padlock Figure 13...
- Page 12 XSM/XTM Series Chief Manufacturing, a products division of Milestone AV Technologies 8805-000259 2008 Milestone AV Technologies, a Duchossois Group Company www.chiefmfg.com 11/08 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe...
